Specifications
Aluminum Foil Container Making Machine1.Good after sales services.
2.Can load many kinds of mould
3.CE certificate.
Aluminum Foil Container Making Machine adopt imported Seimens motor,PLC and Schneider electronic componets to make sure the machine's top quality, the whole line include:
auto-lubricated feeder----control panel----pneumatic press----mould---conveyor---collection desk---packing
1).We are desinging & making mould by ourself for 8 years,after finishing the mould,we testing on machine time by time to make sure the good quality and high precision,also can according to customer sample to make one cavity.
2).Adopt imported brand & best quality PLC control system and electric components,make sure the producing and running more accurately and steady.
3).This machine equipped with a mould lifter to make sure changing the mould easily by the worker.
4).Our company’s adwantage is that:we can according to your target price and requirment to make the right model for you.
ISO9001:2008 standard
Technical data:
ITEM |
CYAL-45T |
CYAL-63T |
Strokes |
40-75times/min |
30-70times/min |
Motor Capacity |
6.5KW |
8KW |
Voltage |
3-380V 50HZ 4wires |
3-380V 50HZ 4wires |
Total Weight |
6500KGS (approximate) |
7500KGS (approximate) |
Area |
7mx3m |
7mx3m |
Press Dimension |
1620x1050x2960 |
1820x1250x3080 |
Core Coil Head Dia |
3min/6inch |
3min/6inch |
Max. Foil Roll Outer Dia |
700mm |
800mm |
Max. Foil Width |
550mm |
670mm |
Whole Line Pic:
Machine part PIC:
Feeding:
