Help CenterNew Type Nonwoven Zipper Bag Making Machinery
Related Products
-
2013 Wenzhou Zipper Woven Non-woven Plstic Bags Making MachineUS$ 17,000 - 25,000MOQ: 1 Set -
Non-woven Zip Lock Bag MachineUS$ 17,000 - 25,000MOQ: 1 Set
-
Non-woven Zip-lock Bag Making MachineUS$ 17,000 - 25,000MOQ: 1 Set
-
China Non-woven Zipper Standing Bag Making MachineUS$ 17,000 - 25,000MOQ: 1 Set
-
China Non-woven Zipper Plastic Bag Making MachineUS$ 17,000 - 25,000MOQ: 1 Set
Specifications
new type nonwoven zipper bag making machinery1:High production speed and high output
2:High quality and high bonding strengt
new type nonwoven zipper bag making machinery
USE
This Zipper Bag Making Machine is suitable to making zipper lock bag.
Performance and Characteristics:
1.This machine uses fully automatic servo motor with computer digital function to control length, it is easy for operation. The produced one is very tight and fast at the seals, it apparently shows a good quality.
2.Flow process of production is from rolled material through automatic edge alignment, edge trimming, strip piercing laminating, ultrasonic compressive embossing, photo cell sensing, hole punching, thermo cutting off and ends with automatic counting ,all of the operations are fully automatic.
3.This machine equips automatic stop equipment, it will work to stop the machine when it is running out of material supply or when photo cell is out of order or when temperature is losing down and below the minimum required.
Main technical variables | |||
Model |
HBL—Z600 |
HBL—Z700 |
HBL—Z800 |
Production speed |
20-100PCS/min |
20-100PCS/min |
20-100PCS/min |
Bag width |
100-600mm |
100-700mm |
100-800mm |
Bag length |
50-500mm |
50-600mm |
50-700mm |
Bag thickness |
30-100g |
30-100g |
30-100g |
Power supply |
380v/220v |
380v/220 |
380v/220 |
Total power |
6.8kw |
7.6kw |
8.2kw |
Overall size |
6200×1170×1800 |
6200×1270×1800 |
6200×1350×1800 |
Sample:
Workshop
Delivery
The Certificates
Our Company Culture
The Payment Term
