Specifications
1. use for PE film2. computer control
3. easy operation
use
The machine is suitable for heatsealing and thermal cutting of such plastic films as LDPE and HDPE etc. And it is a kind of ideal equipment for specially producing vest bags of natural color and multicolor
Performance
an innovatively designed sealing and cutting device , and convenient to adjust the pressure seal cutter, the overall turnover up to 180 degrees for easy cleaning and replacement of adhesive tape.
Characteristics
1. import reflective photoelectric switch control, smooth and reliable feeding, automatically stopping the machine when the color mark is lost.
putercontrolled machine microcomputer, stepper motor drag material (optional servo motor control system), seal cutting precise dimension.
3.automatic counting and counting alarm and the whole output system can to be set.
4.imported equipment of frequency conversion motor to make a smooth, energyefficient, centralized from the oil system.
Main technical parameters
Model | DFR-800 |
Maximum width | 780mm |
Sealing and Cutting Length | 999mm |
Sealing and Cutting Thickness | 0.008~0.0251pcs/min |
Capacity | 120~240pcs/min |
Total Power | 7kw |
Machine Weight | 950kg |
Dimensions | 2800×1400×1350mm |
computer heat-sealing &heat-cutting bag making machine
