ST036S + ST040PP Automatic cover making machine and gluing machine
- 5 Set / Sets per Month
- Shenzhen
- T/T
- Non-woven PUR Hot Melt Laminating Machine for Fabric/film/garment/sofa/mattress/underwear
- Automatic PUR Hot Melt Laminating Machine for medical fabric laminating machine
- PUR hot melt Laminating Machine for automotive interior parts lamination
- PUR hot melt laminating machine for Nonwoven/Film/foam/Fabric/EVA/PU/PP
- Automatic Hot Melt Coating Machine for medical fabric laminating machine
- Fabric/film/non-woven Hot Melt Coating Machine for garment/sofa/mattress/underwear
Product Details
Condition: | New | Application: | Other, Machinery & Hardware | Packaging Type: | Cartons |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 14KW | Place of Origin: | Guangdong, China |
Brand Name: | ST | Model Number: | ST 036B | Dimension(L*W*H): | 4000X2000X1680MM |
Weight: | 4000KG | Certification: | CE |
Product Description
Specifications
Automatic cover making machine and gluing machine1.Max size:680x400mm
2.Min size:150x100mm
3. Speed:10~36 pcs/min
ft s
Main parameter of Automatic cover making machine:
Max size: | 680x400mm |
Min size | 150x100mm(can making spical size:100mmx85) |
Speed | 10~36 pcs/min |
Voltage | 380V |
Power | 10KW |
Center board width | 6-100mm |
Gutter Width | 3-13mm |
Flaps Bending | 7-14mm |
Board thickness | 0.8-5mm |
Sponge Matted Boards thickness | 1-8mm |
Machine weight | 4200kg |
Machine case color | red+beige |
MACHINE SIZE | 3500mmx3500mmx2000mm |
Function & Feature of Automatic cover making machine:
Automatic cover making machine has national patent, whole computer function argument setting and troubleshooting display function. Automatic cover making machine has auto-gluing for standard book board cover, two side board & center board position setting, edge finishing, parallel leveling. Smart control glue pre-melt, auto lubricating system, model change quickly, digital interface display for your work pieces adjusting easily..The max quantity of the Irregular cardboard reach to 7 pcs
Technical parameters for automatic cover gluing machine:
Max size | 680mmx400mm |
Min size | 100mmx150mm |
Speed | 42pcs/min |
Voltage | 380V |
Electric Power | 3.2KW |
Machine weight | 2800kg |
Machine size | 4200x1600mmx1400mm |
Machine case color | red+white |
Function of automatic cover gluing machine :
1. automatic cover gluing machine is applies to cold glue, and make the glue equally and can cycle usage, reducing the cost and improve the effective. automatic cover gluing machine is applies to glue the insied lining paper of finished catable calendar, file folder, gift box, mobile phone box, moon cake case, book cover, cover of notebook, garment box, etc.
2. The automatic cover gluing machine equips Japanese OMRON PLC intelligent software control system, automatic error inspection which display directly on the touch screen and auto stop, enables the operator easily solve the problem and save the material.
..........
The combination of ST036 + ST040PP can be completed in one time for producing hardcover and gluing end paper perfectly, and achieve full automation.
