IP68 Best Heat Dissipatio LED Underwater Light

IP68 Best Heat Dissipatio LED Underwater Light photo-1
IP68 Best Heat Dissipatio LED Underwater Light photo-2
IP68 Best Heat Dissipatio LED Underwater Light photo-3
IP68 Best Heat Dissipatio LED Underwater Light photo-4
IP68 Best Heat Dissipatio LED Underwater Light photo-5
US$ 24 - 38 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
Epistar, Bridgelux, Epileds
Input Voltage(V):
AC/ DC 12V
Lamp Power(W):
12
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source Epistar, Bridgelux, Epileds
Input Voltage(V) AC/ DC 12V
Lamp Power(W) 12
Lamp Luminous Flux(lm) 350±10%Lm
Lamp Luminous Efficiency(lm/w) 85
Color Temperature(CCT) Other, RGB
Working Temperature(℃) -20, 50
Working Lifetime(Hour) 30000
Lamp Body Material Stainless Steel
IP Rating IP68
Certification CE, EMC, FCC, LVD
Place of Origin Guangdong, China
Brand Name Heguang Lighting
Model Number HG-P38U-9*1W/12*1W

LED underwater light IP68

Product Description



Features (Advantages):

316 (V4A) stainless steel LED underwater light, unique heat-dissipation & waterproof design, high-grade and artistic, wide application.

Transparent PC cover, anti-corrosion, shock-proof, unbreakable, safe transportation

IP68 structure waterproof

RGB Synchronization with our patented remote control system (Patent No.: ZL 2012 2                0640518.8)

high power 1w as light source, Epistar, Bridgelux, Epileds as led chip for options.

Color: Red, Green, Blue, RGB, 14 kinds of color changing mode

     Single color – white, red, green, blue, yellow

5 kinds of RGB control method: Remote control, Wi-Fi Control, DMX Control,

     Automatic control, External control (wire control)

Constant driver to make sure LED light working stable, avoid any flashing and noisy

l Over-current protection



Specification

Parameter

Model No.

HG-P38U-9*1W

HG-P38U-12*1W

LED Qty.

9 pcs 1W High power

12 pcs 1W High power

Input Voltage

AC/DC 12V

AC/DC 12V

Input Frequency

50/60 Hz

50/60 Hz

Power

10±1 W(W/G/B/RGB)

6±1 W(red)

13±1 W(W/G/B/RGB)

8±1 W(red)

Luminous flux

600±10%Lm(P.W)

580±10%Lm(W.W)

550±10%Lm(C.W)

200±10%(R) / 400±10%(G)

80±10%(B) /260±10%(RGB)

780±10%Lm(P.W)

750±10%Lm(W.W)

700±10%Lm(C.W)

280±10%(R) / 520±10%(G)

120±10%(B) /350±10%(RGB)

Color temperature

p.w.6000~7000k

w.w.:3000-3500k

c.w.8000~10000k

p.w.6000~7000k

w.w.:3000-3500k

c.w.8000~10000k

Wave Length

R:620-630 K/nm

G:515-525 K/nm

 B:460-470 K/nm

R:620-630 K/nm

G:515-525 K/nm

 B:460-470 K/nm

Dimension

147×123 mm

147×123 mm

Working temperature

-20~50℃

-20~50℃

Storage Temperature

-20~50℃

-20~50℃

Base

wire

wire

Picture Show

    IP68 best heat dissipatio LED underwater lightIP68 best heat dissipatio LED underwater light

9W 12W size:

IP68 best heat dissipatio LED underwater light



Installation:

IP68 best heat dissipatio LED underwater light



Remote control: RGB Remote control (with RGB controller):IP68 best heat dissipatio LED underwater light

RGB Controller Connection diagram:

IP68 best heat dissipatio LED underwater light

Applications



Applications: garden pond, square, water column, flower-bed in villas, garden, rocky water-fall, outdoor fountain, etc.

 IP68 best heat dissipatio LED underwater light

LED underwater light IP68

Packaging & Shipping

IP68 best heat dissipatio LED underwater light



Company Information

IP68 best heat dissipatio LED underwater lightIP68 best heat dissipatio LED underwater lightIP68 best heat dissipatio LED underwater light



Exhibition show

IP68 best heat dissipatio LED underwater lightIP68 best heat dissipatio LED underwater lightIP68 best heat dissipatio LED underwater light

LED underwater light IP68



Our Services

Our products

IP68 best heat dissipatio LED underwater light

CE, RoHs Compliance

All our products are IK10, CE, RoHs,and FCC compliance.



Customer range

Europe(France, Germany, Netherland, Belgium, Italy, UK, Spain, Poland, Sweden, etc.)

North American(U.S.A., Canada, Mexico)

South America( Brazil, Argentina, Chile, etc).

Australia, New zealand; Africa(South Africa, Egypt, etc.)

Asia(Singapore, Japan, Thailand, Malaysia, etc.),



M.O.Q.

Gernerally, we don’t require M.O.Q. in order to help some clients to expand their business & keep the ball rolling.



Lead time

7-13 working days based on stock material and order quantity.



Payment

T/T, Western Union or LC(at sight)



Incoterms

EX-Factory/work, FOB, CIF



Warranty

All our products are covered by 24 months warranty from the date of purchase

We are not responsible for any damage caused by unproper use/assembling or force majeure
