IP68/LED Underwater/Pool Light
Product show:
Model No.: HG-P20U-3*1W / HG-P30U-6*1W
Features:
l 316 (V4A) stainless steel LED underwater light, unique heat-dissipation & waterproof design,
high-grade and artistic, wide application.
l Transparent PC cover, anti-corrosion, shock-proof, unbreakable, safe transportation
l IP68 structure waterproof
l high power 1w as light source, Epistar, Bridgelux, Epileds as led chip for options.
l 5 kinds of RGB control method: Remote control, Wi-Fi Control, DMX Control,
Automatic control, External control (wire control)
l Constant driver to make sure LED light working stable, avoid any flashing and noisy
Applications: garden pond, square, water column, flower-bed in villas, garden,
rocky water-fall, outdoor fountain, etc.
|
|
|
Main Parameters:
Specification |
Parameter |
|
Model No. |
HG-P20U-3*1W |
HG-P30U-6*1W |
LED Qty. |
3 pcs 1W High power |
6 pcs 1W High power |
Input Voltage |
AC/DC 12V |
AC/DC 12V |
Input Frequency |
50-60 Hz |
50-60 Hz |
Power |
4±1 W(W/G/B/RGB) 3±1 W(R) |
7±1 W(W/G/B/RGB) 5±1 W(R) |
Luminous flux |
200±10%Lm(P.W) 180±10%Lm(W.W) 170±10%Lm(C.W) 60±10%(R) / 130±10%(G) 28±10%(B) / 90±10%(RGB) |
390±10%Lm(P.W) 370±10%Lm(W.W) 350±10%Lm(C.W) 120±10%(R) / 260±10%(G) 50±10%(B) / 180±10%(RGB) |
|
Wave Length (RGB) |
R:620-630 K/nm G:515-525 K/nm B:460-470 K/nm |
R:620-630 K/nm G:515-525 K/nm B:460-470 K/nm |
Color temperature |
p.w.6000~7000k w.w.:3000-3500k c.w.8000~10000k |
p.w.6000~7000k w.w.:3000-3500k c.w.8000~10000k |
Dimension |
124.5×115 mm |
124.5×115 mm |
Working temperature |
-20~50℃ |
-20~50℃ |
Storage Temperature |
-20~50℃ |
-20~50℃ |
Base |
wire |
wire |
Constant driver |
yes |
yes |
IP rating |
IP68 |
IP68 |
|
Constant driver & over-current protection |
yes |
yes |
Packing |
45 pcs in 64.5x45x42cm master carton N.W.: 14.5 kgs |
45 pcs in 64.5x45x42cm master carton N.W.: 15 kgs |
RGB Control methods
Our underwater light series:
Installation diagram:
Packaging:
1 pc in a white box, 45 pcs in 64.5x45x42cm master carton N.W.: 14.5 kgs
it also can be customized based on the customers' requirements.
Shipping:
7-15 working days, it also depends on your order quantity.
1.OEM or ODM------Our advanced production lines, precise equipment, strict quality control process
and experienced engineer team are capable to fulfill the toughest OEM or ODM
requirement from customers worldwide.
2.M.O.Q.-------Generally, we don’t require M.O.Q. in order to help some clients to expand
their business & keep the ball rolling.
3.Lead time------7-15 working days based on stock material and order quantity.
4.Payment------T/T, Western Union or LC(at sight)
5.Incoterms-------EX-Factory/work, FOB, CIF
6.Warranty------All our products are covered by 24 months warranty from the date of purchase.
We are not responsible for any damage caused by improper use/assembling or force majeure.
Advantages of Our Pool Light:
1. Absolutely RGB Synchronized
(Patent No.:ZL 2012 2 0640518.8)
RGB control system which make sure of RGB Synchronization.
2. IP Rating: IP68
Patented design (structure waterproof ) &100% high pressure water-proof test.
3. RGB Remote control, DMX512 control, WiFi & external control, Automatic control.
4.300W Pool light replacement: over 3200Lm
5. Lamp body material options:
(Patent No.: ZL 2011 2 0512723.1)
316 stainless steel, plastic or aluminium(anti-corrosion)
SHENZHEN HEGUANG LIGHTING CO., LTD. is a sophisticated manufacturer which specializes in R&D and
production of LED Light ODM & OEM in fields of LED Swimming Pool Light and Underwater Light as well as
fountain light, inground light, wall washer, etc.
