Home > Lights & Lighting > LED Interior Lighting > LED Spotlight > TIWIN 5W Warm White SLCF Spotlight
Negotiable
MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
TE-R11
Warranty(Years):
2
Input Voltage(V):
AC220V~240V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TIWIN Cool White SLCF LED LOW POWER 3W SpotlightNegotiableMOQ: 20 Pieces -
TIWIN 2014 New Product Xinglang 12w LED Grille LampNegotiableMOQ: 10 Pieces
-
TIWIN 9W 12W 15W Commercial Cob Led Track Light With White Black Body FinishNegotiableMOQ: 20 Units
-
15w 4000k 100-240VAC TRACK LED LightNegotiableMOQ: 50 Pieces
-
TIWIN NEW PRODUCTS 2700K 10w LED SpotlightUS$ 15 - 15MOQ: 50 Pieces
LED Light Source
TE-R11
Warranty(Years)
2
Input Voltage(V)
AC220V~240V
Lamp Power(W)
5
Lamp Luminous Flux(lm)
465
Lamp Luminous Efficiency(lm/w)
85
Color Temperature(CCT)
Warm White
Working Temperature(℃)
-25, 40
Working Lifetime(Hour)
25000
Lamp Body Material
Aluminum
Certification
CCC
Place of Origin
Jiangsu, China
Brand Name
TIWIN
Model Number
SLCF0501A3U-S530RD5N101
Specifications
Special spring buckle design, easy to install .COB chip, collecting light and clean shade,Isolated LED Driver supply| JIANGSU TIWIN OPTO-ELECTRONICS TECHNOLOGY CO.,LTD. | |||||||
| Document ID | Product Specification | Version | 1.01 | ||||
| Compile Date | Page | 2014/1/1 | |||||
| Photo | | Item | Specifications | ||||
| Name | SLCF spotlight | ||||||
| Product specification | AC220V~240V,50/60Hz 3W/5W | ||||||
| Size | Φ85*55mm, Cut-Out:Φ75mm | ||||||
| Installation method | Embedded mounted | ||||||
| dimensions | | ambient temperature | —25~40C° | ||||
| Angle adjustment | No | ||||||
| Control method | No | ||||||
| IP grade | IP20 | ||||||
| Rated lifespan | ≥25000H | ||||||
| standard | GB7000.1-2007 | ||||||
| material | die-casting aluminum | ||||||
| Power Efficiency | 82% | ||||||
| PF | 0.5 | ||||||
| Installations component | Snap-in | ||||||
| color | pink | ||||||
| CPD | | Beam angle | 35° | ||||
| Luminous flux | 255lm/465lm | ||||||
| CCT | 3000K/5700K | ||||||
| CRI | Ra≥80 | ||||||
| Brand | Toplite | ||||||
| Lamp type | TE-R11 | ||||||
| specification | 1 pcs chips, 0.13KG/PCS | ||||||
| specification | output:280mA | ||||||
| Inner box size | K3A 3 layers: 234x130x73 (mm) | ||||||
| Carton size | A=B 5 layers: 392x280x51 (mm) | ||||||
| weight(Kg) | N.W =8kg | ||||||
| packing | 25pcs inner boxes per carton,2 pcs lights in per inner box | ||||||
