TIWIN Cool White SLCF LED LOW POWER 3W Spotlight

Name: TIWIN Cool White SLCF LED LOW POWER 3W Spotlight
Brand: TIWIN
SKU: 123737141
Availability: InStock

Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

LED Light Source:

TE-R11

Warranty(Years):

Input Voltage(V):

AC220V~240V

Jiangsu Tianying Opto-Electronics Technology Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source TE-R11

Warranty(Years) 2

Input Voltage(V) AC220V~240V

Lamp Power(W) 3

Lamp Luminous Flux(lm) 465

Lamp Luminous Efficiency(lm/w) 85

Color Temperature(CCT) Cool White

Working Temperature(℃) -25, 40

Working Lifetime(Hour) 25000

Lamp Body Material Aluminum

Certification CCC, CE

Place of Origin Jiangsu, China

Brand Name TIWIN

Model Number SLCF0501A3U-S557RD5N101

	JIANGSU TIWIN OPTO-ELECTRONICS TECHNOLOGY CO.,LTD.

Document ID		Product Specification			Version	1.01
Compile Date					Page	2014/1/1
Photo			Item	Specifications
			Name	SLCF 5W 3W spotlight
			Product specification	AC220V~240V,50/60Hz 3W/5W
			Size	Φ85*55mm, Cut-Out:Φ75mm
			Installation method	Embedded mounted
dimensions			ambient temperature	—25~40C°
			Angle adjustment	No
			Control method	No
			IP grade	IP20
			Rated lifespan	≥25000H
			standard	GB7000.1-2007
			material	die-casting aluminum
			Power Efficiency	82%
			PF	0.5
			Installations component	Snap-in
			color	pink
CPD			Beam angle	35°
			Luminous flux	255lm/465lm
			CCT	3000K/5700K
			CRI	Ra≥80
			Brand	Toplite
			Lamp type	TE-R11
			specification	1 pcs chips, 0.13KG/PCS
			specification	output:280mA
			Inner box size	K3A 3 layers: 234x130x73 (mm)
			Carton size	A=B 5 layers: 392x280x51 (mm)
			weight(Kg)	N.W =8kg
			packing	25pcs inner boxes per carton,2 pcs lights in per inner box
