Specifications
Water Chiller for induction heating machine1. Max. Tem. Resistance is 95 deg.
2. High-strength of fiber glass re
Water Chiller For Induction Heating Machine
Technical Parameter of JLLS-3 Water Chiller
Model Parameter | LJLS-3 | ||||
Cooling Capacity | kcal/h | 8500 | |||
KW | 7.91 | ||||
Input power | KW | 3.33 | |||
Power Supply | 3PH~380V/50HZ | ||||
Refrigerant | Model | R22 | |||
Type Control | Capillary | ||||
Compressor | Type | Wholly-Sealed Vortex Type | |||
Power | KW | 2.25 | |||
Condenser | Type | Efficient Copper-Pipe Setting in the Aluminum-Fin Type + Low-noise External Rotor Fan | |||
Cooled Air Flow | m3/h | 3000 | |||
Evaporator | Type | Water Tank with Coil Tube | |||
Refrigerated Water Flow | m3/h | 1.36 | |||
Water Tank Capacity(L) | 65 | ||||
Inlet and Outlet pipe caliber | 1″ | ||||
Water Pump | Power (KW) | 0.375 | |||
Lift(M) | 20 | ||||
Safety Protection | Compressor overheating protection, Overflow protection, High and low pressure protection, Over temperature protection, Flow protection, Phrase sequence/ Phrase-lacking protection, Exhaust over heating protection | ||||
Weight of the Machine | KG | 135 | |||
MEAS. | MM | 930×610×860 | |||
Note: 1. The cooling capacity is according to:
Refrigerated water inlet and outlet temperature 12°C/7°C; Cooling air inlet and outlet temperature 30°C/38°C
2. Working Range:
The temperature range of Refrigerated water is from 5°C to 35°C; The inlet and outlet temperature difference is from 3°C to 8°C.
The machine can be used while the temperature is below 35°C.
We reserve the right to change the above dimensions or parameters without further notice.
