Specifications
Hot Sale Industrial Water Cooling System1. The temperature range of Refrigerated water is from 5 to 35
Hot Sale Industrial Water Cooling System
Features:
1) Good shape with small outside size, light weight
2) Optimum structure
3) The cooling tower body is made of FRP, which is anti-aging, anti-corrosion, without fading and distortion
4) Min. Noise: The lowest noise blower and unique noise elimination technology is adopted to reduce the noise to a minimum level
5) with reliable operation: All steel structure brackets are galvanized and corrosion resistant. The usage life is twice longer compared with similar products
6) Simple operation and maintenance: CTNC intelligent control system is adopted to realize labor free management
7) The angles of all the fans are regulative and axial-flow, which are made of advanced engineering plastics.
8) All the motors are sealed, which can be used in the severe weather and circumstances.
9) The casing and water plate of the cooling tower are made of fiberglass, which will not be corroded, and no painting is needed. They can be used for a long time with very low maintenance cost.
10) The radiating film is made of polyvinyl chloride hard and heat-resisting.
The temperature in the water is up to 54. C and the special structure enables the water to touch the film in the biggest area with low air resistance. The energy exchanging efficiency is very high.
| Model Parameter | JL-AC-8(D) | |||
| Cooling Capacity | kcal/h | 17604 | ||
| KW | 20.47 | |||
| Input power | KW | 9.25 | ||
| Power Supply | 3PH~380V/50HZ | |||
| Refrigerant | Model | R22 | ||
| Type Control | Capillary | |||
| Compressor | Type | Hermetic Scroll (piston) | ||
| Power | KW | 3.8*2 | ||
| Condenser | Type | Efficient Copper-Pipe Setting in the Aluminum-Fin Type + Low-noise External Rotor Fan | ||
| Cooled Air Flow | m 3 /h | 8000 | ||
| Evaporator | Type | Water Tank with Coil Tube | ||
| Refrigerated Water Flow | m 3 /h | 3.52 | ||
| Water Tank Capacity(L) | 120 | |||
| Inlet and Outlet pipe caliber | 1″ | |||
| Water Pump | Power (KW) | 0.75 | ||
| Lift(M) | 22 | |||
| Safety Protection | Compressor overheating protection, Overflow protection, High and low pressure protection, Over temperature protection, Flow protection, Phrase sequence/ Phrase-lacking protection, Exhaust over heating protection | |||
| Weight of the Machine | KG | 320 | ||
| MEAS. | MM | 1300 × 720 × 1350 | ||
