Specifications
Metal U-Bolt Induction Heater1.IGBT technology.
2.Perfect protection function.
3.Converting frequency technique
Metal U-Bolt Induction Heater
Main Feature
1. IGBT inversion technology reduce operating cost
2. The absolute load merit rate design, can work continuously for 24 hours.
3. The digital phase locked realizes following frequency automatically
4. Design in modules It s installed facility and use conveniently
5. The perfect protection function ,insuring the reliability and easily maintaining of the equipments
6. The technique of converting frequency by resonance promotes efficiency of whole equipment by over 95% efficiently
7. Economically ,and environmental protection ,it can replace of the gas/ coal /electronic tube induction heating machine
The whole set including
1).One Generator , One Transformer; 2). Two induction coils;
3). One foot switch; 4). One Instruction Manual;
5). One Product certificate of quality; 6). One warranty card
Model |
JLC-30KW |
|
Input power desire |
3 phase 380V 50/60HZ |
|
Oscillate power max |
30KW |
|
Max input current |
48A |
|
DC current |
60A |
|
Oscillate frequency |
10-30KHZ |
|
Timing |
1M-99.99M 1S-99.99S 0.01S-99.99S |
|
Cooling water desire |
0.2Mpa |
|
Duty cycle |
100% 40°C |
|
Dimensions(L*W*H) |
Generator |
400*550*810mm |
transformer |
420*330*450mm |
|
Net weight |
60kg/30kg |
|
Cable length |
2-6(Meters) |
|
Application:
