Specifications
CNC Bus Bar Processing Machine1.CE and ISO2008
2.High efficiency
3.Good price
CNC Bus Bar Processing Machine BM303-S-3-8P
Muti-functional Busbar Processing Machine is a self-developed new product of our company. Main Features as follows:
1.The punching unit has turret tooling library,it maximally can hold 8(punch and embossing )dies or 7 punch dies and 1emossing die;
2.The Bend Unit adopts overall structure,angular CNC method, operation is simple and high accuracy;
3.The machine adopts dual layer platforms design scheme,three units can be operated at the same time without disturbing each other.
4.The machine is equipped with auto refueling and draining system ,the operation is simple and convenient,the hydraulic oil enters oil tank through the filter,which can protect the whole hydraulic system from any contamination;
5.The machine adots stainless steel oil tank,which can guarantee no corrosive degeneration of the hydraulic oil and extend the usage life span of hydraulic oil and each sealing parts;
6.PLC control,stable and reliable.
Configuration
Dimensionofplatform(mm) |
Weight(Kg) |
motor |
Total power
|
voltage
|
hydraulic station |
Control method |
|
Layer 840×370 |
1460 |
4 |
11.37 |
380 |
3×31.5 |
PLC+bending angle mumerical control |
Main specification and Technical parameter
Items |
Materials |
Processing Thickness×Width |
Maximum punch |
Maximum output power |
Punch unit |
Copper/Aluminum |
Thickness 15mm |
Ø32(Thickness<10mm) Ø25(Thickness<15mm) |
350KN |
Shear Unit |
Copper/Aluminum |
15×160mm/12x160mm |
350KN |
|
Bend Unit |
Copper/Aluminum |
15×160mm/12x120mm |
350KN |
