Home > Instruments & Meters > Test Instrument > Test Machine > Handheld 2.8" PON Power Tester

Handheld 2.8" PON Power Tester

Handheld 2.8" PON Power Tester thumbnail-3

Handheld 2.8" PON Power Tester thumbnail-4

Handheld 2.8" PON Power Tester thumbnail-5

Handheld 2.8" PON Power Tester thumbnail-6

US$ 404 - 530 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Business Type:

Manufacturer, Buying Office, Distributor/Wholesaler

Year Established:

1996

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

MITS COMPONENT & SYSTEM CORP.

Payment & Shipping

Payment Methods:

Port of Shipment:

TPE

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

Part number: OPM-003

Model	OPM-003
Calibrating wave length	1310nm	1490nm	1550nm
	InGaAS
Isolation	1490nm >40dB 1550nm >40dB	1310nm >40dB 1550nm >30dB	1310nm >40dB 1490nm >30dB
Measurement range (dBm)	Burst mode:-35~+10 Stable :-40~+10	-50~+10	-45~+20
Spectral Passband(nm)	1310±20	1490±10	1550±10
Connatural uncertainty (dB)	≤ 0.5
Resolution(dB)	0.01
Pass through Insertion Loss (dB)	≤ 1.5
Optical Fiber Model	SM
Connector Type	FC (FC,SC,ST connector)
Other parameter
Optical power meter (optional)	Detector Type: InGaAs Wavelength: 850/1300/1310/1490/1550/1625nm Measurement range: -70~+10dBm Uncertainly: ±5% Display Resolution: Linear::0.1% Nonlinear:0.01dBm Connector type: FC/SC/ST
Threshold setting	10 groups
Data storage	1000 sets
Communication Port	USB
Power	Lithium Ion Polymer Battery(3000mAh)
Working time	≥20 hours
Operating Temperature	-10℃ to 60℃
Humidity	0 to 95%(non-condensing)
Weight	480g
Dimensions (H×W×T)	112×189×47mm

>>>" href="http://message.china.cn/msgsend/contact.htm?action=contact_action&domain=2&id=230306189&id_f=IDX1JOwVC8_mShyzFqh5j65cioCBGZIYP6-BxdiEqrkuxJUWt1KC7wOJymVzQxeDMl2s&mloca=main_site_contacts&umidToken=B3a41a2559deec3e948e90172809a27b0" target="_blank">Contact us now >>>>

Packaging & Shipping

We ship whatever you ask, by DHL/UPS/FEDEX/EMS, air or ocean shipment.

Accept small, trial orders, and customised orders too!

Our Services

Please note: All of our product's delivery term is: Ex-work Taiwan, the FOB pricing is for reference only
If there is any product information needed, please contact us or consult online
