Help CenterHandheld XPON Optical Power Multimeter, MITS Taiwan, FTTX/PON Networks, Fiber, Ethernet/UTP Cable Testing, PON System Testing
Related Products
-
2.4GHz, 5GHz WiFi Spectrum Tester, WFT-2458, MITS Taiwan, Handheld Tester, IEEE 802.1a/ b/ g/ n Standard, Roaming TestNegotiableMOQ: 1 Unit -
All-in-One 3.5" Handheld CCTV/IP Camera Tester - IPT-3500, MITS Taiwan. TDR Tester, Visual Fault Locator, Cable FinderUS$ 175 - 180MOQ: 1 Unit
-
MITS All-in-One 4.3" Handheld CCTV IP Camera Tester - TDR Tester, Visual Fault Locator, Cable FinderUS$ 252 - 252MOQ: 1 Piece
-
OPM-005 Optical Power Meter, MITS Taiwan, CATV Fiber, REF, Alarm, Wavelength Auto-identify, Self-calibrating, Multi- CalibratedUS$ 115 - 130MOQ: 1 Unit
-
MLS-001 Multi-wavelength Laser Source, MITS Taiwan, Handheld, CATV Fiber, Passive Optical Network, Adjustable Optical Power,US$ 200 - 250MOQ: 1 Unit
Applications
Features
* Simultaneous Wave length: 1310/ 1490/ 1550 (nm)
* Dual measurement ports, upstream burst and detection at 1310/1490/1550(nm)
* Optional 850/1310/1490/1550/1625 oftest optical power.
* Working time: above 20 hours.
* Relative power test can set the time. Up to 10 groups user defined threshold.
* Data Storage: 1000 sets
* Power Type: USB Communication enable data transfer to a PC, convenient and saves time
* Set the threshold, through software, data upload, and wavelength calibration.
* Easy for operation, just simply connect the fiber to read the data
* Quick on-site test to and measurement of the PON signals, anywhere on the network.
* Operating Temp.: -10°C to 60°C
Highlights
* 2.8 inch TFT-LCD. Brightness, Contrast, Saturation adjustable
* UTP cable testing, test and display the cable line and number
* DC12V/1A power output for ONU, and test optical power.
* Quick ,on-site test and measurement of the PON signals, anywhere on the network
* Three Indicator light shows the fiber state, pass, warn and fail.
* Set the threshold through software, data upload and wavelength calibrate.
Model |
OPM-002 |
||
Calibrating wave length |
1310nm |
1490nm |
1550nm |
|
InGaAS |
||
Isolation |
1490nm >40dB 1550nm >40dB |
1310nm >40dB 1550nm >30dB |
1310nm >40dB 1490nm >30dB |
Measurement range (dBm) |
Burst mode:-35~+10 Stable :-40~+10 |
-50~+10 |
-45~+20 |
Spectral Passband(nm) |
1310±20 |
1490±10 |
1550±10 |
Connatural uncertainty (dB) |
≤ 0.5 |
||
Resolution(dB) |
0.01 |
||
Pass through Insertion Loss (dB) |
≤ 1.5 |
||
Optical Fiber Model |
SM |
||
Connector Type |
FC (FC,SC,ST connector) |
||
Other parameter | |||
Optical power meter (optional) |
Detector Type: InGaAs Wavelength: 850/1300/1310/1490/1550/1625nm Measurement range: -70~+10dBm Uncertainly: ±5% Display Resolution: Linear::0.1% Nonlinear:0.01dBm Connector type: FC/SC/ST |
||
Threshold setting |
10 groups |
||
Data storage |
1000 sets |
||
Communication Port |
USB |
||
Power |
Lithium Ion Polymer Battery(3000mAh) |
||
Working time |
≥20 hours |
||
Operating Temperature |
-10°C to 60°C |
||
Humidity |
0 to 95%(non-condensing) |
||
Weight |
480g |
||
Dimensions (H×W×T) |
112×189×47mm |
||
Please note: All of our product's delivery term is: Ex-work Taiwan
If there is any product information needed, please contact us or consult online
