High quality stainless steel 4 inch pressure gauge with bottom connection
All stainless steel pressure gauge
Crimped ring
Liquid fillable
Highly accurate
Outdoor and severe ambient and process conditions
Use where harmful vibration and pulsation are present
Hydraulic equipment, pressure washers, oil field equipment, pumps,
compressors and process systems
Dial |
1.5″,2″,2.5″,4″(40mm,50mm,63mm,100mm) |
Scale ranges |
-1—1000bar |
Accuracy class |
1.5″(40mm),2(50mm):±2.5% of full scale 2.5″(63mm),4″(100mm): ±1.5% of full scale |
Process connection |
1⁄8″,1⁄4″NPT or 1/2″NPT standard with restricted orifice |
Bourdon tube |
316LSS,drawn seamless |
Wetted parts/socket |
Stainless steel 304 or 316 |
Movement |
316SS |
Pointer |
Aluminum,micrometer adjustable |
Welding |
TIG,Laser Welding |
Case material |
stainless steel 304,DIN bayonet |
Window(lens) |
tempered glass,safety glass |
Fill |
glycerin |
IP class |
IP 65 |
Options/notes:
Lower or back entry, panel mount or surface mount.
