China Supplier 1000V Digital Megger Megohmmeter Quality Choice
US$ 10 - 99
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
HuaZheng
Model Number:
UT501
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin/1000V Digital megger megohmmeter
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UT207A Factory Wholesale 3 3/4 1000A AC/DC Digital Clamp MeterUS$ 104.5 - 107.5MOQ: 1 Piece -
UT620B Factory Wholesale Digital Micro Ohm Meters,Milliohm MeterUS$ 410 - 423MOQ: 1 Piece
-
UNI-T UT107 Handheld Automotive Multi-Purpose MeterUS$ 19 - 69MOQ: 1 Piece
-
High Accuracy Uni-t 2000A Digital Clamp Meter UT221US$ 35 - 152MOQ: 1 Piece
-
Digital Handheld Spectrum Analyzer With Tracking Generator USBUS$ 8,786.5 - 8,793.5MOQ: 1 Piece
Place of Origin
Hebei, China
Brand Name
HuaZheng
Model Number
UT501
china supplier 1000V Digital megger megohmmeter
The supplier of State Grid! IEC156 ISO 9001:2008 ASTM | |
Product Description
china supplier 1000V Digital megger megohmmeter parameter:
| Specification | Range | Best Accuracy | |
| Model | UT501 | ||
| Insulation Resistance(Ω) | Test Voltage | 250V/500V/1000V | 0~10% |
| 250V | 3MΩ~2000MΩ | ±(3%+5) | |
| 500V | 3MΩ~2000MΩ | ±(3%+5) | |
| 1000V | 3MΩ~2000MΩ | ±(3%+5) | |
| Test Current | 250V(R=250KΩ) 1mA | ±10% | |
| 500V(R=500KΩ) 1mA | ±10% | ||
| 1000V(R=1MΩ) 1mA | ±10% | ||
| Short Circuit Current | <2mA | ||
| DC Voltage (V) | 30V~1000V | ±(2%+3) | |
| AC Voltage (V) | 30V~750V | ±(2%+3) | |
| Features | |||
| Display Count | 1999 | ||
| Auto Range | √ | ||
| Low Battery Indication | √ | ||
| LCD Backlight | √ | ||
| Alarm Light Display | √ | ||
| Alarm Buzzer | √ | ||
| High Voltage Indication | √ | ||
| Over Load Indication | √ | ||
| Auto Discharge | √ | ||
| General Characteristic | |||
| Power | 1.5V Alkaline Batteries(LR6) X 6 | ||
| LCD Size | 70.6mm X 34mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 500g | ||
| Product Size | 150mm X 100mm X 71mm | ||
| Standard Accessories | Batteries, Probe ,Alligator Clip, Test Lead, Carrying Bag,Gallus | ||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 20 PCs | ||
| Standard Carton Measurement | 500mm X 380mm X 330mm (0.063 CBM Per Export Carton) | ||
| Standard Carton Gross Weight | 10.5 Kg | ||
After-Sales Service
From the date of purchase within one year instrument, is a product quality problem free repair replacement, lifetime supply of maintenance and technical services. The instrument has found anomalies or malfunctions please contact us to arrange the most convenient treatment options.
Certifications
Contact Lily Niu
Lily.Niu
TEL: 0086-312-3372757-804
Skype:Lily.niu8
Alibaba: cn1511851602
Web:
Huazheng Electric Manufacturing (BaoDing) Co.,Ltd (Factory)
Factory add.:Longxing Road 77,Baoding, Hebei,China
Office add.:Room 510 Chaoyanglong zuo B Building No.1178Chaoyang street, Baoding ,Hebei,China
