Digital Storage Oscilloscope With Bulit-in Function Generator

Models

UPO5202CS

UPO5204CS

UPO5352CS

UPO5354CS

UPO5502CS

UPO5504CS

Bandwidth

200 MHz

350 MHz

500 MHz

Channels

2

4

2

4

2

4

Sample Rate

4GS/s(Single-channel),2GS/s(Dual-channel)

Max. Memory Depth

256Mpts(Single-channel),128Mpts(Dual-channel)

Waveform Capture Rate

200,000wfms/s

Time Base Scale

UPO550X/UPO535X:1ns~1000s;UPO520X:2 ns~1000s

Input Coupling

(1MΩ±1%)//(14pF±3pF);(50Ω±2%)//(14pF±3pF)

Vertical Scale

1 mV/div ~ 5 V/div(1 MΩ);1 mV/div ~ 1 V/div(50 Ω)

DC Gain Accuracy

±3%

Waveform Record

Max. 300,000 Frames

Trigger

Edge,Pulse Width,Runt,Nth Edge,Slope,Video,Pattern,RS232/UART,I2C,SPI,CAN,USB,FlexRay

Bus Decode

Standard:Parallel;Optional:RS232/UART,I2C,SPI,CAN,USB,FlexRay

Waveform Operation

A+B,A-B,A×B,A/B,FFT,Editable Advanced


Auto Measurement

Peak-Peak Value, Amplitude, Maximum, Minimum, Top Value, Bottom Value, Mean, Average, Root Mean Square Value, Overshoot, Preshoot, Frequency, Cycle, Rise Time, Fall Time, Positive Pulse, Negative Pulse, Positive Duty Ratio, Negative Duty Ratio, Delay 1->2, and Delay 2->1.

Number of Measurements

Display 5 measurements at the same time

Measurement Statistic

Average, Max, Min, Standard Deviation, Number of Measurements

Frequency Counter

Hardware 6 bits counter (Channels are selectable)

Standard Interface

USB-Host(×2), LAN, VGA Output, 10MHz Input/Output, AUX Output (TrigOut, GND, Pass/Fail)

General Characteristic

Power

100V~240VACrms, 45Hz~440Hz

Display

9 inches, TFT LCD, WVGA(800×480)

Product Color

White and Gray

Product Net Weight

4.4 Kg ± 0.2 Kg

Product Size (W×H×D)

456mm × 218mm × 128mm

Standard Accessories

Probe×2/4(1×,10× switchable),Power Cord ,USB Cable, PC Software CD

Standard Individual Packing

Gift Box, English Manual

Standard Quantity Per Carton

1 PC

Standard Carton Measurement (L×W×H)

445mm×395mm×275mm

Standard Carton Cross Weight

7.2 Kg
