Intelligent Low Voltage Active Power Filter
US$ 3,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
Zhongsheng
Model Number:
APF
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Power Quality Filter 3Phase 4WireNegotiableMOQ: 1 Set -
Magnetic Control Reactor Static Var Compensator (MCR-SVC)NegotiableMOQ: 1 Set
-
Active Filter for 400VAC 50Hz 500AUS$ 40,000 - 45,000MOQ: 1 Set
-
SVC / Static Var CompensatorNegotiableMOQ: 1 Set
-
STBB Series Electric Power Saving EquipmentNegotiableMOQ: 1 Set
Place of Origin
Hubei, China
Brand Name
Zhongsheng
Model Number
APF
Product Description
| Product name | Intelligent low voltage active power filter | ||||
| Three phase, three wire | |||||
| Model no. | SAPF-50/380-I | SAPF-100/380-I | SAPF-150/380-I | SAPF-200/380-I | SAPF-300/380-I |
| Compensate current | 50A | 100A | 150A | 200A | 300A |
| Dimensions (w*d*h) | 800*600*2200mm | 800*600*2200mm | 800*800*2200mm | 1000*800*2200mm | 1200*800*2200mm |
| Rated voltage | 380V | ||||
| Rated frequency | 50Hz | ||||
| Filter tuned to | 2th to 50th, or order of harmonics. | ||||
| Starting time | less than 10ms. | ||||
| Mounting arrangement | indoor | ||||
| Enclosure IP class | IP30 | ||||
| Standards | IEC 60831, GB 7251, GB/T14549 | ||||
| Temperature class | -10℃ to +40℃ | ||||
| Relative humidity | no more than 85%, non condensing. | ||||
| Altitude | no more than 2000m. | ||||
| Installation site | Vertical inclination shall be no more than 5 degree. No fire hazard, explosion risk, conductive dust, corrosive gas and strong vibration exist. | ||||
| Applications | The low voltage active harmonic filter cabinet is widely used in process industries such as cement, metal, chemicals and pharmaceuticals, as well as industries such as textiles, automobiles, health care, petrochemicals, datacenters, and more. | ||||
Picture of product
