Top mounted 19"swimming pool sand filter from China supplier

Specifications

1) 1.5"-2.0" DN
2) 6 positions valve sand filter
3) Top mount design swimming pool sand filter
4) Customize made

Hydroswim Top mounted sand filter,swimming pool sand filter,fiberglass sand filter

F/HS/T350--F/HS/T350



Applications



This kind of sand filter is particular for home swimming pool,water park water treatment,water purifying and water fitration



Feature and advantage

1.The sand fitler adopt materials used are dependable and suitable for all the weather performance.

2.Easy-to-use muliport valve let us select any of the valve / filter operation with a simple lever-action.

3.Filter 's UV resistance surface allows the sand fiber to work under direct sunlight.



Technology Data

Model No.	Valve Height (mm)	Valve Port Size(mm)	Filter Area(m2)	Silica Sand(kg)	Design Flow(lpm)	Gross Weight(kg)
F/HS/T350	450	50	0.1	20	80	12
F/HS/T400	510	50	0.13	30	105	16
F/HS/T450	570	50	0.16	40	133	16.5
F/HS/T550	610	50	0.22	85	192	21.1
F/HS/T650	730	50	0.3	155	270	24.3
F/HS/T700	795	50	0.4	185	320	33
F/HS/T800	930	63	0.5	210	420	41.5
F/HS/T900	1030	63	0.64	310	500	52.3
F/HS/T1000	1130	63	0.79	410	550	95
F/HS/T1100	1210	63	0.98	460	630	115
F/HS/T1200	1330	63	1.13	560	700	124
F/HS/T14000	1580	63	1.54	900	950	182.5
