Help CenterSix-Position Fiber Glass Top Mount Sand Filter
Related Products
-
Horizontal Fiberglass Sand FilterUS$ 1,784 - 4,083MOQ: 2 Sets -
Fiberglass Reinforced Polypropylene FilterUS$ 608 - 773MOQ: 5 Sets
-
High Flow Clean & Clear FilterUS$ 248 - 356MOQ: 5 Sets
-
Energy Efficient Swimming Pool FilterUS$ 607 - 773MOQ: 5 Sets
-
Fiberglass Reinforced Polypropylene Material, Vertical Grid FilterUS$ 634 - 840MOQ: 5 Sets
Specifications
fiberglass top mount sand filter6-position valve
UV resistance surface
resistance to chemical corrosion
easy to use
Fiber Glass Top Mount Sand Filter
Feature and the advantage:
1.Materials used are dependable and are suitable for all the weather performance.
2.Easy-to-use multi port valve let us select any of the valve/ filter operation with a simple lever-action.
3.UV resistance surface allows the fiber to work under direct sunlight.
Application:
Suitable for filtering pools, aquariums, water parks and industrial wastewater treatment equipment .
Technical Information:
Model No. |
TANK Dia. B(mm) |
Height A(mm) |
Valve Height C(mm)
|
Valve Port Size (mm) |
Filter Area (m2) |
Silica Sand (kg) |
Design Flow (lpm) |
Gross Weight (kg) |
Package Sizes (cm) |
Package Type (material) |
350 |
350 |
680 |
450 |
50
|
0.10 |
20 |
80 |
12.0 |
36*36*70 |
Master Carton
|
400 |
400 |
740 |
510 |
0.13 |
30 |
105 |
16.0 |
48*48*78 |
||
450 |
450 |
800 |
570 |
0.16 |
40 |
133 |
16.5 |
49*49*83 |
||
550 |
550 |
840 |
610 |
0.22 |
85 |
192 |
21.1 |
57*57*71 |
||
650 |
650 |
960 |
730 |
0.30 |
155 |
270 |
24.3 |
68*68*83 |
||
700 |
700 |
1025 |
795 |
0.40 |
185 |
320 |
33.0 |
73*73*86 |
||
800 |
800 |
1200 |
930 |
63 |
0.50 |
210 |
420 |
41.5 |
84*84*96 |
|
900 |
900 |
1300 |
1030 |
0.64 |
310 |
500 |
52.3 |
94*94*108 |
||
1000 |
100 |
1400 |
1130 |
0.79 |
410 |
550 |
95.0 |
107*107*125 |
Wooden Crate |
|
1100 |
1100 |
1480 |
1210 |
0.98 |
460 |
630 |
115.0 |
117*117*135 |
||
1200 |
1200 |
1600 |
1330 |
1.13 |
560 |
700 |
124.0 |
127*127*144 |
Wooden Pallet |
|
1400 |
1400 |
1850 |
1580 |
1.54 |
900 |
950 |
182.5 |
145*145*160 |
Remark:
- Payment: 70% T/T prepaid,Western Union.
- Terms of payment:All payment are before shipment .
- Price will be adjusted if USD:RMB rate varies by +/- 2%. Freight not included .
- Offer validity: one month
We Provide high-quality service for:
1,Swimming pool equipment wholesalers.
2,Retailers and online shops.we have shops in Chengdu,Shanghai,Beijing and Guangzhou,We supply the high quality and low price,and best service.
3,OEM-The custom-made pumps are available.Upon customer’s idea,drawings,photos etc.more detail.The length of time depend on the procedures .
Addr: Fl.2, No.166, Gangdong Rd., Dashi street, Panyu District, Guangzhou.China.
Tel: +86 20 34796181 Fax: +86 20 34796171
