FX octagonal tube cold roll forming machine for shutter door
- 6 Set / Sets per Month
- xingang
- T/T Credit Card
Product Details
Condition: | New | Type: | Tile Forming Machine | Tile Type: | Colored Steel |
Use: | Roof | Production Capacity: | 6SETS/MONTH | Place of Origin: | Hebei, China |
Brand Name: | XINGBO | Model Number: | FX-Stone-coated | Power(W): | 101kw |
Voltage: | 380v50hz3p | Dimension(L*W*H): | 56*1.2*1.5m | Weight: | about 60T |
Certification: | BV CE ISO | Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
FX octagonal tube cold roll forming machine for shutter door
Features:
1.Light weight,environmenttal protection and economical
2.Durability and life-long service
3.Easy installed
4.Nice appearance and fashion windproof
1.Components and Details of FX octagonal tube cold roll forming machine for shutter door
(1)Automatic bottom glue spraying equipment,
Outside Dimension | 4000 × 1350 × 850mm(L*W*H) |
Transmission | 2.2kw,variable-frequency,adjustable-speed,motor0-32R/Min |
Conveying device | Beciprocating chain conveys |
Automatic glue spraying assembly | with motor 0.06kw |
Adsorption of dust removal equipment | 1 set |
Air compressor | 1 set 0.9m |
Automatic pressure glue canister | 1 set range of adjustable pressure 0.1-0.6MPa |
Automatic glue spraying gun | 4 sets |
Fill glue gun | 5 sets |
Glue gun stand | 1 set |
(2)Automatic sandblasting room ,
Outside Dimension | 3000 ×1850 ×700mm(L*W*H) |
Transmission | With glue spraying equipment compound chain transmit |
Conveying device | Compound chain transmit |
Automatic sand hopper | 1 set dimension 550*600*500mm |
Automatic rising machine | 1 set with rising height 1.9m power 300kg/h |
Sun-blasting gun | 4 sets |
(3)First drying room,
Outside Dimension | 25000 ×800 ×1200mm(L*W*H) |
Frame type heat preservation wall | Fill up with heat preservation material which is bended with 1mm carbon steel |
Automatic temperature controller | 2 sets,range of adjustable temperature 0-160°C |
Infrared fluorescent tube | 50 pcs |
Conveying device | Reciprocating chain conveys |
Cooling device | 1 set |
(4)Automatic surface glue spraying equipment,
Outside Dimension | 3000 ×850 ×700mm(L*W*H) |
Automatic glue spraying gun | 2 sets |
Automatic spraying assembly | 1 set range of pressure 0.1-0.6MPa |
Adsorption of dust removal equipment | 1 set |
Manual spraying gun | 5 sets |
(5)Second drying room equipment,
Outside dimension | 30000 ×850 ×700mm(L*W*H) |
Frame type heat preservation wall | Fill up with heat preservation material which is bended with 1mm carbon steel |
Conveying device | Reciprocating chain conveys |
Infrared heat tube | 50 pcs |
Automatic temperature controller | 2 sets,range of adjustable temperature 0-160°C |
Conveying device | Reciprocating connection conveys 30m |
Cooling device | 1 set |
Automatic printing code and marking | 1 set of automatic printer |
Real use of house roof:
1.we will arrange the shipment within 45 working days upon confirmation of purchasing order or recepit of deposit.
2.Package :Adopt the wood pallet package,the waterproof film outside,every pallet has 400 pcs tile,about 1000kgs,1'20GP can load about 7200-9000pcs according to the different destinations.
