Hot SM LX-MM SX Mode Conditioning Fiber Optic Patch Cord
Hot SM LX-MM SX Mode Conditioning Fiber Optic Patch Cord manufactured by ANC International Co., Limited is
a duplex multimode cord that has a small length of single mode fiber at the start of the transmission leg. These are tested utilizing the industries latest equipment for superior quality. Mode Conditioning Patch cords are assembled with connectors using 62.5/125um or 50/125um fiber. Fully compliant with IEEE 802.3z application standards, this cable is used where high speed gigabit 1000Base-LX routers and switches are deployed into existing multimode plants. The need for this patch cord is due to the single-mode launch nature of the -LX or long-wave (1300 nm) transceiver modules used for gigabit Ethernet. Launching a single-mode laser into the center of a multimode fiber can cause multiple signals to be generated that confuse the receiver at the other end of the fiber.
Specification
Core Diameter: 50/125 micron
Insertion loss: typically <0.20 dB
Return loss: >35dB
FOCIS-3 TIA/EIA-568-B.3 compliant
Used primarily during deployment of new high-speed routers/switches in existing multimode backbone
Ultra Physical Contact (UPC) Polished Fiber
Built with Corning Glass
Features
Ceramic Ferrules for increased durability
RoHS compliant for all mode-conditioning patch cords material
Usage
Telecommunication
Long haul networks
CATV networks
Building interconnections
Technical Data
Item |
Parameter |
|
Single-mode |
Multi-mode |
|
Insertion Loss |
≤0.3dB |
|
Return Loss |
≥50 dB (PC), ≥60 dB (APC) |
|
Repeatability |
≤0.1dB |
|
Durability |
0.2dB Max. 1000 mattings |
|
Operating Temperature |
-40℃~+85℃ |
|
Storage Temperature |
-40℃~+85℃ |
|
