Manufacturer MM OM3 Duplex LC FDDI AMP Fiber Optic Patch Cord
MM OM3 Duplex LC FDDI AMP Fiber Optic Patch Cord manufactured by ANC International Co., Limited uses AMP FDDI connector that features a sliding keyway that is integrated into the connector body. The keyway is indexed to achieve the prescribed FDDI keying positions. Key positions A and B are used with dual attach stations. M and S keying positions are used when a network concentrator is connected to a single attached station. M key is inserted at the concentrator and the S key at the station end. The type S or "slave" key position will mate with any connector regardless of key style.
Specification
ANSI FDDI compliant single mode and multimode versions optional
Integrated indexed sliding keyway accommodates all key position and eliminates need to remove and insert individual keys
Polarized to ensure proper mating
Terminates with standard 213 hex crimp
Universal bend limiting boot accommodates zip cord or round cable
Mechanically isolated free floating fiber alignment ferrules
Connector housing quickly and securely snaps together, no screws
Features
Enhanced cable retention
RoHS compliant for all FDDI fiber optic patch cords material
Usage
Telecommunication
FDDI Data Network
LAN, FTTX
CATV
Technical Data
Insertion Loss (IL) |
Typical 0.2dB |
Return Loss (RL) |
>40dB for jumpers up to 3m |
Strain Relief |
200N |
Durability |
Min 500 cycles |
Assembly Procedure |
Glue and polish |
Connection |
Physical contact |
Standards |
ANSI X3T9.5 |
Ferrule Material |
Zirconia or thermo polymer |
Connector Material |
Thermoplastic (reinforced, flame retardant) |
Adapter Material |
Polymer composite |
ANC manufactures MM OM3 Duplex LC FDDI AMP Fiber Optic Patch Cord and other SC, LC, FC, ST, MU, DIN, E2000, MTRJ, SMA, ESCON, MPO, MTP fiber optic patch cord in Shenzhen, China. The daily capacity for patch cord is 10,000pcs terminators per day. We are good at customized OEM patch cord production. Welcome your inquiry!
