5mm, 5.5mm, 6mm 4/6/12/24 Core Indoor/Outdoor Fiber Optic Cable
Indoor/outdoor Fiber optic cable manufactured by ANC International Co., Ltd is designed for aerial, duct and direct-buried applications with no need for a transition splice when entering the building. The tight-buffered construction facilitates easier termination for low-fiber-count applications in the local area network (LAN) and eliminates need for fan-out kits. The design features TIA-598 color-coded 900 μm TBII® Buffered Fibers for easy identification, consistent stripping and direct termination. The small diameter and bend radius of the cable allow for easy installation in space-constrained areas while the innovative water blocking technology is ideal for OSP applications. The all-dielectric cable construction requires no grounding or bonding and the UV resistant, flame-retardant jacket is rugged, durable and easy to strip. This cable is available in 12 different jacket colors - blue, orange, green, brown, slate, white, red, black, yellow, purple, rose and aqua. The colored jacket allows for easy visual identification of the cables while still providing all of the required environmental protection of an indoor/ outdoor cable jacket. Black is the standard jacket color.
Specification
Can be used both indoor and outdoor applications
Small diameter and bend-radius, Easy installation in space-constrained areas
Color-coded fibers for quick and easy identification
All-dielectric construction, requires no grounding or bonding
Rugged, durable and easy to strip
Material: LSZH, PVC, PE, TPU black color
Usage
Outside plant, inter-building installations
Aerial, duct applications and entrance facilities
Local area networks
Private networks
Technical Data
Cable Type |
Fiber Count |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long/Short Term N |
Crush Resistanc Long/Short N/100mm |
Bending Radius S/D mm |
GYXFTY |
2~24 |
6.0 |
38 |
400/1000 |
300/1000 |
10D/20D |
Optical Characteristics
| ||||||||||||||||||||||||||||||||||||||||||||||||
ANC produces and sells below fiber optic cable.
1. 900um buffer fiber optic cable
2. Simplex/Duplex Zipcord/Duplex Round /Flat Duplex fiber optic cable
3. multi-fiber mini breakout fiber optic cable/distribution fiber cable/Breakout fiber optic cable
4. Indoor FTTH Cable/Outdoor FTTH Cable
5. Air blow fiber optic cable
6. Waterproof fiber optic cable/ indoor & outdoor fiber optic cable
7. Outdoor Cable GYXTW/JET/GYXY/GYTA/GYTS/GYFTY/GYTA53/GYTC8S/GYXTC8Y/ADSS
100% Factory Tested by EXFO OTDR
