6/12/24/36/48 Core Indoor Distribution Optical Fiber Cable
6/12/24/36/48 Core Indoor Distribution Optical Fiber Cable manufactured by ANC International Co., Limited is an integral part of the Panduit end-to-end fiber optic solution, designed to support today's data needs while meeting tomorrow's ever-advancing network requirements. ANC Fiber Optic Distribution Cable is used within buildings to provide high-density connectivity and ease of installation. Applications include intra-building backbones, routing between telecommunications rooms and connectorized cables in riser and plenum environments.
Specification
Good mechanical and environmental properties
Soft, flexible, easy to splice
With big capacity data transmission
Features
Meet various requirements of market and clients
Flame retardant characteristics meet the requirements of relevant standards
Usage
Use in pigtails and patch cords
Used as interconnect lines of equipment
Used in optical connections in optical communication rooms and optical distribution frames
Used in indoor cabling, especially used as distribution cable
Technical Data
Cable Type |
Fiber Count |
O.D. (mm) |
Weight (kg/km) |
Max. Tension |
Crush Resistance |
Long/Short Term |
Long/Short Term |
||||
N |
N/100mm |
||||
GJFJV (Y) |
4 |
4.8±0.2 |
18 |
270/90 |
1000/300 |
GJFJV (Y) |
6 |
5.2±0.2 |
23 |
330/110 |
1000/300 |
GJFJV (Y) |
8 |
6.2±0.2 |
29 |
480/160 |
1000/300 |
GJFJV (Y) |
12 |
6.8±0.3 |
37 |
600/200 |
1000/300 |
GJFJV (Y) |
16 |
7.6±0.3 |
46 |
600/200 |
1000/300 |
GJFJV (Y) |
24 |
8.4±0.5 |
61 |
720/240 |
1000/300 |
GJFJV (Y) |
32 |
10.2±0.3 |
98 |
1000/330 |
1000/300 |
GJFJV (Y) |
36 |
10.5±0.5 |
110 |
1000/330 |
1000/300 |
GJFJV (Y) |
48 |
12.5±0.5 |
126 |
1200/520 |
1000/300 |
Options
Types of fiber: G.652 A/B/C/D or G.655 A/B/C Single-mode fiber, A1a or A1b multimode fiber, or other types of fiber
Material of jacket: Flame-retardant polyvinyl chloride (PVC), low smoke zero halogen flame retardant polyolefin (LSZH), thermoplastics polyurethane (TPU), or other contracted material
Color of Jacket: (including the color of fiber in cable core) meets the requirements of relevant standards, or other contracted color
Cable dimension: The nominal diameter, or other contracted
Delivery Length: 1km or 2km, or other contracted length
Other requirements: Other contracted individual requirements
ANC produces and sells below fiber optic cable.
1. 900um buffer fiber optic cable
2. Simplex/Duplex Zipcord/Duplex Round /Flat Duplex fiber optic cable
3. multi-fiber mini breakout fiber optic cable/distribution fiber cable/Breakout fiber optic cable
4. Indoor FTTH Cable/Outdoor FTTH Cable
5. Air blow fiber optic cable
6. Waterproof fiber optic cable/ indoor & outdoor fiber optic cable
7. Outdoor Cable GYXTW/JET/GYXY/GYTA/GYTS/GYFTY/GYTA53/GYTC8S/GYXTC8Y/ADSS
100% Factory Tested by EXFO OTDR
