Help CenterEcoturn 500/1000 CNC Inclined Bed Lathe
Related Products
-
Turnado 280/1500 V Lead Screw and Feed Shaft LatheUS$ 1,000 - 10,000MOQ: 1 Set -
Turnstar 200S CNC Horizontal LatheUS$ 1,000 - 10,000MOQ: 1 Set
-
Turnstar 200C CNC Horizontal LatheUS$ 1,000 - 10,000MOQ: 1 Set
-
Turnado 280/2000 V Lead Screw and Feed Shaft LatheUS$ 1,000 - 10,000MOQ: 1 Set
-
Turnado 280/3000 V Lead Screw and Feed Shaft LatheUS$ 1,000 - 10,000MOQ: 1 Set
Heavy-duty CNC Lathe for cost-effective machining of large parts and series production
- heavy inclined bed design and rigid headstock were FEM-analyzed and optimized in the design phase
- extra-wide, hardened rectangular guides with plastic-coated counter-guides ensure quiet operation and long-term precision - even for complex manufacturing tasks, like heavy roughing work or intermittent cuts
- a total of 5 high-precision spindle bearing groups ensure optimum turning results, even at high axial and radial loads
- exact positioning hydraulic 8-station tool turret
- excellent chip removal and standard chip conveyor support an efficient and cost-effective machining operation
- hydraulic tailstock and hydraulic hollow chuck can be controlled via foot switch (standard)
- efficient coolant system with coolant nozzles at every tool mount
- Fanuc 0i-Mate TD with Manual Guide 0i scores with high reliability and maximum availability
- high-quality preloaded ball screws with powerful servo-axle-drive ensure excellent positioning accuracy and repeatability at high axle dynamics
|
Working area
Workpiece length (max.)
Center height
Turning diameter over bed
Turning diameter over support
|
1.000 mm
255 mm
505 mm
340 mm
|
|---|---|
|
Travels
Travel X-axis
Travel Z-axis
|
250 mm
1.100 mm
|
|
Headstock
Speed range
Headstock torque
Spindle mount
Spindle bore
Spindle bore with draw tube
|
50 - 3.000 rpm
171 Nm
A2-6
65 mm
52 mm
|
|
Rapid feed
Rapid feed X-axis
Rapid feed Z-axis
|
8.000 mm/min
12.000 mm/min
|
|
Tool head
Number of tool stations
Tool shank dimensions
Boring bar mount diameter
|
8 Pieces
25x25 mm
40 mm
|
|
Tailstock
Tailstock taper
Tailstock quill diameter
Tailstock quill stroke
|
MT 5
100 mm
100 mm
|
|
Accuracies
Positioning accuracy X-axis
Positioning accuracy Z-axis
Repeatability X-axis
Repeatability Z-axis
|
0,016 mm
0,025 mm
0,007 mm
0,01 mm
|
|
Drive capacity
Motor rating main drive
Main drive, continuous load
Motor rating X-axis
Motor rating Z
|
18,5 kW
15 kW
1,2 kW
1,8 kW
|
|
Measures and weights
Overall dimensions (length x width x height)
Weight
|
3.735x1.500x1.750 mm
4.500 kg
|
Fanuc 0i-Mate TD mit Manual Guide 0i
High Performance for Excellent Productivity
- Easy creation of complex contours
- Advanced fixed cycles, graphical support
- G & M Code help
- ISO CODE Programming Assistant
- DIN / ISO Programming
- Graphic simulation for reliable control of NC programs
- High compatibility with existing Fanuc CNC programs
A wealth of world-class functions in the Basis CNC ensures maximum productivity
- Port for storage card, processing of storage card in DNC operation
- High-Performance digital Servo System on all axes
- optional free M Codes
- optional relay outputs
- RS232 port
- multiple languages
- User-friendly graphic display for visual review of parts program
- Advanced help function and alarm/operating archive
- 64 tool compensation pairs
- Tool life-cycle management: The tools can be subdivided in groups. The life times and tool numbers for each group that are stored in the NC control can be shown in an easy to read table format.
- consistent cutting speed
- process time and parts counter
Standard Equipments:
Fanuc 0i-Mate TD with Manual Guide 0i, chip conveyor, electronic hand-wheel, 8-station turret, hydr. tailstock, hydraulic hollow chuck 300 mm, automatic central lubrication, coolant system, center MT 5, machine feet, fastening bolts, operating tools, operating manual and programming instructions
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
