Medium Head Turgo Turbine

Name: Medium Head Turgo Turbine
Brand: BOCHI
SKU: 123429017

US$ 15,000 - 800,000 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

BOCHI

Model Number:

Bochi Machinery Corporation (Chongqing)

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name BOCHI

Model Number XJ

Type Generator

Electricity Generator Type Hydro Power

Output Voltage (V) 400

Specifications

Turgo Turbine ( inclined jet turbine ) water turbine.
1.Power: 20kw~1500KW
2.Frequency: 50hz or 60hz
3.Water head:70-200m

	Alibaba Recommended Supplier Alibaba Excellent Supplier

1.Power: 20kw~1500KW

2.Frequency: 50hz or 60hz
3.Output Voltage:400V, 6.3KV or 13.8KV
4.Output Type: AC three phase
5.Lifespan: 30~50year

6.Bochi Turgo turbine's working Water head:70-200m

Model type: XJA-W

Highly efficient Big, Medium and Small Turgo Turbine (inclined jet turbine, special type Pelton turbine, used for medium head with small flow).
Equipments would be produced according your request.
There should be some key parameters (such as head, flow discharge and capacity, if need turbine generator too, please supply the frequency and output voltage, if not, give us the rotation speed) in inquiry.
Note: Bochi can design and manufacture various types of hydro generator units with 0.42-7m in turbine runner diameter and 20KW-200MW in unit capacity, such as Tubular type, Axial(Kaplan) type, Francis type, Inclined jet(Turgo) type and Impulse(Pelton) type ones, and auxiliary equipments.

Production Capacity
Product Name		Production Line Capacity			Actual Units Produced (Previous Year)
Kaplan Turbine		35 Sets Per Year			5 Sets
Francis Turbine		65 Sets Per Year			9 Sets
Pelton Turbine		25 Sets Per Year			4 Sets
Turgo Turbine		12 Sets Per Year			3 Sets
Speed Governor		60 Sets Per Year			8 Sets
Surge Valve		20 Sets Per Year			5 Sets
Production Machinery
Machine Name	Brand & Model No.		Quantity	Number of Year(s) Used		Condition
Lathe	CQ5250C		7	8		Acceptable
Boring Mill	N/A		1	5		Acceptable
Facing Machine	N/A		2	9		Acceptable
Drilling Machine	N/A		2	5		Acceptable
Milling Machine	N/A		1	13		Acceptable
Welding Machine	N/A		9	5		Acceptable
Testing Machinery
Machine Name	Brand & Model No.		Quantity	Number of Year(s) Used		Condition
X-Ray Machine	N/A		1	3		Acceptable
Quality Management System Certification
Certification	Certified By		Certificate No.	Business Scope		Validity Period
ISo9001:2008	CQC, CNAS		00110Q22699R0M/5100	Production of Sized Hydraulic Turbine		18/Mar./2010 -- 17/Mar./2013
