Specifications
Sanyyo belt conveyer1, return belt conveyor
2, as a whole no joints
3, thick roller
Certificate: ISO9001:2000
The application of Belt Convey :
Mass flow by conveying is by far the dominating method when transporting material in a minerals processing operation. Sanyyo Machinery offers the optimum solution whether you requirement is for dry, wet or sticky material, and to both horizontal and vertical applications. We also meet your wear protection needs.
Sanyyo Machinery delivers the worlds most comprehensive range of conveyor belts. Based on more than 22 years of experience in development, manufacture and applications knowhow, belts and belt systems are designed to meet specific end user requirements for high performance and cost efficiency.
The Features and Benefits of Belt Convey :
The belt conveyor can be used to transfer bulk materials or materials in pieces.According to different transferring requirements, the transferring system can be of only one belt conveyor or consists of several conveyors, or combined with other transferring equipments. The belt conveyor can be installed horizontally or aslope to meet the needs of different transferring requirements.
The Belt Convey Working Principle:
The motor drives the driving rollers of the belt conveyor, and drives the roller by the strong belt advances. Materials are conveyed from the original place to the place where they are needed.
The Belt Convey Technical Specifications:
Belt Width(mm) |
Belt Length (m) /Power (kw) |
Belt Speed(m/s) |
Capacity(t/h) |
|||
500 |
12/3 |
12-20/4-5.5 |
20-30/ 5.5-7.5 |
1.3-1.6 |
45-100 |
|
650 |
12/4 |
12-20/5.5 |
20-30/7.5-11 |
1.3-1.6 |
70-120 |
|
800 |
6/4 |
6-15/5.5 |
15-30/7.5-15 |
1.3-1.6 |
120-180 |
|
1000 |
10/5.5 |
10-20/7.5-11 |
20-40/11-12 |
1.3-2.0 |
160-250 |
|
1200 |
10/7.5 |
10-20/11 |
20-40/15-30 |
1.3-2.0 |
200-400 |
|
...
