Specifications
SANYYO vibrating screen, latest desigh and High precision to screen stones/sand,firm structure with long service lifeSANYYOYK series vibrating screen
SANYYO vibrating screens for scalping, separating and sizing aggregates, minerals and coal come in several different types and a wide range of sizes. We offer screens for both wet and dry applications, and the screening media for optimum end product quality. We also offer both individual units and complete systems, as well as expert advice on choosing the right screen for the job. Our equipment is easily adaptable for stationary and mobile crushing plants. Its main function is to separate different sizes of products. SANYYO vibrating screen has the ability of seperating six different sizes of products in the same time.
YK series Features and values
1)Simple and dependable Eccentric type system.
2)High screening capacity.
3)High durability.
4)No transmission of screen panels.
5)Ready changing of screen plates.
6)Rigid and vibrating resistance screen body.
Vibrating screen’s operating principle:
In screen grading, the material is separated mechanically on screen plates. Rolling bearings in vibrating screens are stressed by high, mostly shock-type loads. Moreover, the bearings, while rotating about their own axis, perform a circular, elliptical or linear vibrating motion. This results in high radial accelerations which additionally stress the bearings, and especially the cages, considerably. The operating speeds are usually very high. As a result, the bearing temperatures are up to 20 to 30 degrees Kelvin higher than in normal applications. In addition, considerable misalignments between the bearing locations and considerable shaft deflections have to be accommodated.
Model |
No.of screen decks |
Screen size(mm) |
Max.feedsize(mm) |
Capacity (t/h) |
Vibrating frequeny (Hz) |
Motor power(kw) |
Weight (kg) |
3YK-1245 |
3 |
1200×4500 |
200 |
15-80 |
16.2 |
11 |
4807 |
3YZ-1548 |
3 |
1500×4800 |
200 |
30-200 |
13-16 |
15 |
6866 |
4YZ-1548 |
4 |
1500×4800 |
200 |
30-250 |
13-16 |
18.5 |
7360 |
2YK-1854 |
2 |
1800×5400 |
250 |
50-300 |
16.2 |
18.5 |
6769 |
3YK-1854 |
3 |
1800×5400 |
250 |
50-300 |
16.2 |
22 |
8285 |
4YK-1854 |
4 |
1800×5400 |
250 |
50-300 |
16.2 |
30 |
9796 |
2YK-2160 |
2 |
2100×6000 |
250 |
100-400 |
16.2 |
30 |
9680 |
3YK-2160 |
3 |
2100×6000 |
250 |
100-400 |
16.2 |
30 |
10206 |
3YK-2460 |
3 |
2400×6000 |
300 |
150-600 |
16.2 |
30 |
12350 |
DF-1230 |
1 |
1200×3000 |
200 |
20-200 |
16.2 |
5.5 |
1540 |
DF-1548 |
1 |
1500×4800 |
250 |
50-450 |
16.2 |
15 |
3750 |
DF-1854 |
1 |
1800×5400 |
300 |
70-600 |
16.2 |
15 |
4590 |
DF-2160 |
1 |
2100×6000 |
300 |
120-750 |
16.2 |
15 |
5423 |
...
