Specifications
SANYYO sand crusher specialize in reshaping of granula and sand-making, widely used in fine-crushing of rocks, pebbleVSI crusher introduction
VSI crusher is used for artificial sand making as a secondary crusher. It is used in fine and medium size crushing of coarse material, rocks, stones, minerals, building aggregate concrete and other material. Artificial sand and aggregate is used in preparing good quality concrete for building and construction purpose, so the final product must be cubic with grounded edges. VSI crusher is unbeatable in making a consistence cubicle particle shape, and besides stone, it also can crush iron and ore
SANYYO VSI crusher Features
Innovative Sand Manufacturing Plant
ISO9001:2000, China famous brand, certification of AAA class brand trusted by customer all over the world
Cubical shape of product by stone hiting stone crushing principle
Durable structure,Hydraulic lifting mechanism of upper cover can greatly saves man power during maintenance.
unique closed rotor design providing a higher production ratio with lower wear cost
Little noise and dust pollution
Working principle
The materials fall into the impeller from the head of the machine and with the function of high-speed centrifugal force, they strongly hit against and highly grind the other parts of the materials bypass flowing around the impeller in an umbrella form. After mutual impaction and between the impeller and the machine shell, the materials will move like a vortex and will be impacted, rubbed and pulverized many times. Then they will come to the required fineness controlled by screening equipment, and discharge from the bottom of the machine.
VSI series products:
Model |
Max.feed size(mm) |
Rotor dia. (mm) |
Capacity (t/h) |
power (kw) |
Weight (t) |
Overall dimensions (mm) |
VSI-600 |
60 |
610 |
120 |
160 |
6.5 |
3760x1821x2100 |
VSI-800 |
75 |
813 |
180 |
200 |
7.9 |
4037x2070x2375 |
VSI-1000 |
80 |
1050 |
340 |
250 |
12 |
4890x2386x2678 |
VSI-1200 |
90 |
1260 |
320 |
320 |
16 |
5300x2856x3168 |
...
