Shanghai Portable Crushing Plant Mobile Crushing Plant
US$ 1 - 100,000
/ Set
1 Set(Min. Order)
- Shanghai Qingdao Shenzhen Dalian
- T/T L/C D/P D/A Money Gram
You May Like
Product Details
| Condition | New | Type | Cone Crusher | |
| Application | Building, Cement material, Metallurgy & Mining & Coal,Stone material | Motor Type | AC Motor | |
| Power(W) | 157.5KW | Capacity(t/h) | 80-135TPH | |
| Place of Origin | Shanghai, China | Brand Name | SANYYO | |
| Model Number | SY-PC-100T | Dimension(L*W*H) | 9780*2500*4230 | |
| Weight | 40.223T | Certification | ISO CE SGS GOST | |
| Warranty | 2 years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
| Model | Length (mm) | Width (mm) | Height (mm) | Weight (kg) | Roller weight (kg) | Vibrating feeder | Hopper (m³) | Jaw crusher | Max feeding size (mm) | Min discharge size (mm) | Capacity (t/h) | Belt Conveyor | Power (kw) |
| SY-PJ-50T | 7320 | 2200 | 3520 | 25732 | 12000×2 | GZD250×750 | 6 | PEY400×600 | 350 | 0-125 | 26-75 | B500×6m | 44.7 |
| SY-PJ-80T | 9500 | 2500 | 4000 | 38662 | 16000×2 | GZD100×370 | 10 | PEY500×750 | 450 | 0-150 | 40-130 | B650×8m | 66.4 |
| SY-PJ-100T | 12320 | 2500 | 4323 | 47245 | 16000×2 | GZD100×370 | 10 | PEY600×900 | 500 | 0-150 | 105-182 | B800×12m | 67.9 |
| SY-PJ-150T | 14750 | 3100 | 5422 | 64223 | 16000×3 | GZD490×110 | 15 | PEY750×1060 | 650 | 0-200 | 140-194 | B800×12m | 128.5 |
| SY-PJ-200T | 14750 | 3100 | 5422 | 64060 | 16000×3 | GZD490×110 | 18 | PEY800×1060 | 700 | 0-200 | 180-240 | B1000×12m | 131 |
| SY-PJ-300T | 14750 | 3100 | 6000 | 85000 | 16000×3 | GZD490×110 | 22 | PEY90×1200 | 750 | 0-250 | 250-350 | B1000×12m | 153 |
| SY-PJ-350T | 14750 | 3100 | 6000 | 86000 | 16000×3 | GZD490×110 | 22 | PEY1000×1200 | 850 | 0-250 | 300-400 | B1200×12m | 153 |
| Electrical requirement | 380V-420V, AC(50/60Hz) or according to local standard | ||||||||||||
| Temperature range | -50℃ to 60℃ | ||||||||||||
| Lubricating system | Auto control lubrication oil station, accident alert | ||||||||||||
| Protection system | Hydraulic system | ||||||||||||
| Raw material water content | ≤12% | ||||||||||||
| Support System | Hydraulic | ||||||||||||
| Electric Control system | ABB & Schneider, PLC, Cable | ||||||||||||
| Motor Protection | Dustproof system | ||||||||||||
| Belt Conveyor | Folding | ||||||||||||
| Trailer | Double & Trio. Axles | ||||||||||||
| Magnetic Separator | Automatic discharge | ||||||||||||
| Operation System | Telecontroller | ||||||||||||
| Vibratility | Little | ||||||||||||
| Crush method | Stone to stone crushing | ||||||||||||
| Model | Length (mm) | Width (mm) | Height (mm) | Weight (kg) | Roller weight (kg) | Impact crusher | Vibrating screen | Belt conveyor | Max Feeding size (mm) | Min discharge size (mm) | Capacity (t/h) | Belt conveyor | Belt conveyor | Power (kw) |
| SY-PF-50T | 8250 | 2200 | 3725 | 29535 | 12000×2 | PF1010 | 3YZ1536 | B500×10m | 160 | 25-60 | 45-70 | B500×7m | B500×4m | 91.75 |
| SY-PF-80T | 8250 | 2200 | 3725 | 32535 | 12000×2 | PF1210 | 3YZ1536 | B650×10m | 170 | 25-60 | 60-80 | B650×7m | B650×4m | 126.5 |
| SY-PF-100T | 9780 | 2500 | 4230 | 40223 | 16000×2 | PF1214 | 3YK1850 | B800×12m | 180 | 25-60 | 80-135 | B800×8m | B800×4m | 157.5 |
| SY-PF-150T | 12000 | 3000 | 4500 | 44570 | 16000×3 | PF1315 | 3YK1850 | B800×12m | 200 | 25-60 | 140-180 | B800×9m | B800×4m | 188.5 |
| SY-PF-200T | 12000 | 3000 | 4500 | 49223 | 16000×3 | PF1316 | 3YK2155 | B1000×12m | 215 | 25-60 | 200-230 | B1000×9m | B1000×4m | 258.5 |
| SY-PF-250 | 13000 | 3000 | 5100 | 58223 | 16000×3 | PF1516 | 3YK2155 | B1000×13m | 220 | 25-60 | 220-270 | B1000×9m | B1000×4m | 338.5 |
| Electrical requirement | 380V-420V, AC(50/60Hz) or according to local standard | |||||||||||||
| Temperature range | -50℃ to 60℃ | |||||||||||||
| Protection system | Hydraulic system | |||||||||||||
| Raw material water content | ≤12% | |||||||||||||
| Support System | Hydraulic | |||||||||||||
| Electric Control system | ABB & Schneider, PLC, Cable | |||||||||||||
| Motor Protection | Dustproof system | |||||||||||||
| Belt Conveyor | Antiskid | |||||||||||||
| Trailer | Double & Trio. Axles | |||||||||||||
| Operation System | Telecontroller | |||||||||||||
| Vibratility | Little | |||||||||||||
| Crush method | Stone to stone crushing | |||||||||||||
| Model | Length (mm) | Width (mm) | Height (mm) | Weight (kg) | Roller weight(kg) | Cone crusher | Vibrating feeder | Belt conveyor | Max feeding size (mm) | Min discharge size (mm) | Capacity (t/h) | Belt conveyor | Belt conveyor | Power (kw) |
| SY-PC-80T | 8250 | 2200 | 3725 | 32535 | 12000×2 | CC&HC1000 | 3YZ1536 | B650×10m | 170 | 25-60 | 60-80 | B650×7m | B650×4m | 126.5 |
| SY-PC-100T | 9780 | 2500 | 4230 | 40223 | 16000×2 | CC&HC1160 | 3YK1850 | B800×12m | 180 | 25-60 | 80-135 | B800×8m | B800×4m | 157.5 |
| SY-PC-180T | 12000 | 3000 | 4500 | 44570 | 16000×3 | CC&HC1300 | 3YK1850 | B800×12m | 200 | 25-60 | 140-180 | B800×9m | B800×4m | 188.5 |
| SY-PC-250T | 12000 | 3000 | 4500 | 49223 | 16000×3 | CC&HC1380 | 3YK2155 | B1000×12m | 215 | 25-60 | 200-250 | B1000×9m | B1000×4m | 258.5 |
| Electrical requirement | 380V-420V, AC(50/60Hz) or according to local standard | |||||||||||||
| Temperature range | -50℃ to 60℃ | |||||||||||||
| Protection system | Hydraulic system | |||||||||||||
| Raw material water content | ≤12% | |||||||||||||
| Support System | Hydraulic | |||||||||||||
| Electric Control system | ABB & Schneider, PLC, Cable | |||||||||||||
| Motor Protection | Dustproof system | |||||||||||||
| Belt Conveyor | Antiskid | |||||||||||||
| Trailer | Double & Trio. Axles | |||||||||||||
| Operation System | Telecontroller | |||||||||||||
| Vibratility | Little | |||||||||||||
| Crush method | Stone to stone crushing | |||||||||||||
Feature
Portable Cone Crusher has robust design for the toughest of hard rock crushing requirement. The specific crushing output size can be selected as required to large capacities of top end products. The Compound and Hydraulic Cone crusher units are used in the production of large capacity high end products.
Application
1. Building material
2.Cement material
3.Metallurgy & Mining & coal
4.Chemical
5.Refractory material
6.Quartz & Glass raw material
7.Artificial sandy soil
8.Stone material plant
9.Sand material plant
10.Highway construction and so on
Quality Control
1.The Main Frame is heat treated - which increases tenacity.
2.Welding is of CE Standard.
3.Painting:The machine is sand blasted and painted three times with primer.
4.Warranty:2 years.
5.Hydraulic System.
6.Portable type: Wheel.
Company Information
Shanghai SANYYO Complete Machinery Co., Ltd was founded in 1986. The company gradually turned into joint-stock enterprises, which produces large-sized crushing machinery and provides perfect solution on its own, thanks to the fact that it initially focused on manufacture and research of wear-resistant material. Now the company covers an area of 80,000 square meters and three factories, is well equipped with modernized cutting plant, and has more than 500 people working in the plant. It has changed into an important manufacturer and exporter of crushing machinery, screening, ,Grinder, Ball mill, Diesel generator, Belt conveyor across the world.
