Hot sale jaw crusher 150x250 mini crusher for stone
- 5 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Jaw Crusher | Application: | Mining Quarry Road Building Construction |
Motor Type: | AC Motor | Power(W): | Parameter | Capacity(t/h): | Parameter |
Place of Origin: | Shanghai, China | Brand Name: | SANYYO | Model Number: | PE/PEX |
Dimension(L*W*H): | Specific Model | Weight: | Parameter | Certification: | ISO CE SGS GOST |
Warranty: | 2 Years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Introduction of jaw crusher 150x250 mini crusher for stone.
Jaw crusher are widely applied to medium size bulk materials of various hard and brittle compressive strength of non metal ores, mineral slag, furnace slag, building stone, marble and other less than 320 MPa broken. The crushing ratio can reach 4-6, and product size is uniform. It is used for coarse and middle crushing and is widely used in mining, smelting, building materials, highway, railway, water conservancy and chemical industry and many other industries. In accordance with the feeding port width it can be divided into big, medium, and small crusher. Feeding port width more than 600MM for large machines, in 300-600MM as midrange crusher, feeding port width less than 300MM for mini crusher. PE Series is used in primary crushing, while PEX series is used in secondary crushing and fine crushing.
Feature of mini crusher for stone.
1.Strong and reliable structure.
2.High crushing ratio with large output capacity.
3.Wedge design setting adjustment which allows for the production of different sized material.
4.Lubrication system - safe and reliable, easy to maintain.
5.Can be used in stationary or semi-mobile type.
6.The eccentric shaft is fitted with four bearings, two on each side, S which extends service life.
Working principle of jaw crusher 150x250 mini crusher for stone.
The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves. So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final
crushed stuff will be discharged from the outlet.
Jaw crusher is composed of primary crushing and screening station and secondary one, belt conveyor, etc. Every crushing station is an independent working unit, they can respectively assume their different responsibility, and the belt conveyer is responsible for material transmitting and piling up between each crushing station.
The company:
Shanghai Leiyou Complete Machinery Co., Ltd was founded in 1986, The corporation has its own R&D center, is able to produce large-sized complete crushing machinery,and provide perfect solution.The Corporation,with machines sold annually numbering in thousands, mainly produces good quality marble/granite/gypsum/coal china jaw crusher and screening equipment that are categorized into 30-plus series in more than 300 specifications.The main production of good quality marble/granite/gypsum/coal china jaw crusher.
Products:
We are the specialized in the production of beneficiation machinery in ShangHai. It is China import and export enterprise, China AAA grade quality credit enterprise, ISO9001 international quality certification enterprise and international BV quality and environmental system certification enterprise.
Certificates:
Our Customers:
Provide a solution:
Engineers through the on-the-spot investigation to provide clients with solutions.
Technical training:
In order to guarantee the stability of the production line and run for a long time, after sales engineer on-site guidance to practical personnel training.
On-site maintenance:
Engineers to the scene to solve the problem.
Q: Are you trading company or manufacturer ?
Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 25-30 days if the goods are not in stock, it is according to quantity.
Q: Payment?
A: 30% by T/T in advance once sign the order + 70% before shipment
Q: What about Warranty? what will we do if the machine is broken down?
A: The warranty period for all of huahong’s structural and mechanical equipment is normally two years longer than the other suppliers. Wear parts are not covered in warranty unless the component part is found to be flawed.In the warranty periods,our sales engineers will be to the machine working spot to repair the machines with free of charges.
Q: What should we need to do for if we want to get a best quotation?
A: Hi guiers over the world, if you want to get the correct and exact selection of the model earlier ,please help us with following information.
2.input and output size
3.stone material to be crushed
payment:
1.We usually accept T/T,L/C,D/P,D/A.
2.T/T: 30% in advance as the deposit payment,the balance will be paied before shipemt;
3.We will take pictures of finished products before delivery.
Ways of Packing:
exporting standard packing,for example:wood packing,bulking packing,iron packing,nuded packing,etc.
Transportation:
1.By sea Freight or by air.
2.MSK/MSC/APL/EMC/WANHAI/KLINE/CMA/NDS,etc.Also we could meet the customer's requestments if they have nominated shiping company.
3.In order to meet customer's requestments for tariff preference,we will provide the full set clearance docs,also provide you the CO/CNCA/Form E,etc.
