Brand:DOBRY
Model:GSM800I
Name:
Call termination 8 channel 8 sim GSM voip gateway GSM PCI asterisk card
GSM PCI or PCI-express cards support up to 4/8 GSM channels and enables users to access the mobile network with their existing asterisk,freeswitch,
yate and others. It's more than a GSM card. FXO/FXS can be inserted into the slot to be the hybrid FXO/FXS/GSM cards.
GSM400I/GSM800I have 4/8 slots respectively. Each slot can be inserted with GSM or Single/Dual FXO/FXS modules.
Models:
| models | GSM400I | GSM400E | GSM800I | GSM800E |
| interface | PCI 2.2 | PCI-Express | PCI2.2 | PCI-express |
| channel | 4 | 4 | 8 | 8 |
| weight | 350g | 350g | 700g | 700g |
GSM400I:4 ports PCI GSM Asterisk card.
GSM400E:4 ports PCI-E GSM Asterisk card.
GSM800I: 8 ports PCI GSM Asterisk card.
GSM800E: 8 ports PCI-e GSM Asterisk card.
Features>>
Support the access of wireless(GSM and CDMA), PSTN, Phone.
Support GSM, CDMA two kinds of wireless communication standard.
Support GSM: 850M/900M/1800M/1900M or CDMA: 800Mhz.
Support 4/8 channels, user can choose to insert wireless, FXO or FXS module in each channel.
The PCI slot is based on PCI2.2.
Support the reversal function of polarity when call out by wireless.
32 bit bus master DMA data exchanges across PCI interface at 132Mbytes/sec for minimum host
processor intervention.
supports all the functions of Asterisk PBX systems needed.
Working hardware and software >>
Interface: PCI 2.2
CPU 800+MHZ
RAM 128+MB
Linux kernel 2.4.x or 2.6.x
Working environment>>
Temperature Operation: 0 to 80°C
Temperature Storage: -35°C to 120°C
Humidity: 10% to 90% Non-condensing
Voltage: 5V/12V
Power Dissipation Mas: 7.83w/39.82w
GSM800I Asterisk card X1
antenna X8
converter X1
1 year quality warranty. OEM. Timely After sale service.
