Stainless steel single bag filter housing v band clamp
Negotiable
1 (Min.Order)
- 0 per Month
You May Like
Product Description
Specifications
1. V band clamp for easy handle2. Adjustable legs
3. Durable SS304, SS316L material
4. Accept #1, #2, #3, #4, #5 filter bag
Product Description
Liquapure SBC series stainless steel single bag filter housings are designed with V band clamp closure with max pressure 100 psig(7 bar) for commercial and light industrial water applications. The materials available in SS304 or SS316L.
Features
- V-band clamp closure for quick and easy filter bag change out and secure sealing
- Accept #1, #2, #3, and #4 bags for flow request
- Adjustable heavy duty legs
- High flow rate, low pressure drop
Applications
- Water
- Food & beverage Chemical
- Oil, inks/paints/coatings Coolants
- Pulp & paper
Specifications
Materials of Construction of stainless steel single bag filter housing
Head and body: SS304 or SS316L
Connections: SS304 or SS316L
Closure: SS304
Gasket: Buna
Gasket option:Silicone, EPDM, viton
Finish: polished or sand blast
Filter bags: #1, #2, #3, #4, #5
Max. Pressure: Standard 100 psi(7 bar)
Inlet/outlet connections Inlet/outlet: see table Vent: see table
Option: MNPT, BSP, FLG
| Model | A(mm) | B(mm) | C(mm) | D(mm) | F(mm) | Inlet/Outlet | Flow rate |
| SBC1 | 500 | 380 | 700 | Φ200 | Φ170 | 1"-4" | 15m3/h |
| SBC2 | 700 | 720 | 1050 | Φ200 | Φ170 | 1"-4" | 30m3/h |
| SBC3 | 350 | 190 | 400 | Φ114 | Φ97 | ¾"-2" | 5m3/h |
| SBC4 | 500 | 340 | 540 | Φ114 | Φ97 | ¾"-2" | 10m3/h |
Ordering Guide(Example:SBC2-304-2FNPT-B)
| MODEL | SIZE OF BAG | MATERIAL | CONNECTION SIZE | CONNECTION TYPE | GASKET |
| SBC | 1=#1 bag | 304 | ¾=¾" | FNPT=Femal NPT | B=Buna |
| 2=#2 bag | 316L | 2=2" | MNPT=Male NPT | S=Silicone | |
| 3=#3 bag | … | BSP=BSP | E=EPDM | ||
| 4=#4 bag | 4=4" | V=VITON |
