Help Center3M Equivalent High Flow Filter Cartridges
Related Products
-
Parker Equivalent High Flow Filter CartridgesUS$ 35 - 35MOQ: 1 Piece -
PP Membrane Pleated Filter CartridgeUS$ 2 - 50MOQ: 1 Piece
-
Equivalent to PALL Parker High Flow Filter CartridgeUS$ 20 - 80MOQ: 1 Piece
-
Pleated Filter Cartridges Membrane Pleated Absolute Rate Filter CartridgesUS$ 1 - 10,000MOQ: 1 Piece
-
Membrane Filter Cartridges Pleated Filter Cartridges Absolute Rated Filter CartridgesUS$ 1 - 10,000MOQ: 1 Piece
Liquapure HFM high flow filter cartridges with 6” diameter are designed for higher flow rate filtration systems with fewer filter cartridges than traditional 2.5” pleated filter cartridges or wound and melt blown filter cartridges, which make easy and fast changeout and cost effective. The inside to outside flow direction retains contaminant and particles even during changeout. The high flow cartridges are equivalent to Parker ParMax high flow cartridges and PALL Ultipleat high flow cartridge filters.
Features & Benefits
l 6” diameter for high membrane area and flow rates
l Absolute rated from 1μm to 100μm
l Up to 1200 liters per hour in a single 60” filter cartridges
l Inside-out flow direction trapped contaminant and particulate even when changout
Applications
l RO pretreatment
l Desalination
l Food & beverage
l Process water
l Coolants, cooling water systems
Materials of construction
Filter Media: polypropylene, Fiber glass
Support Media: polypropylene
Support core: coreless or polypropylene core
Out cage: polypropylene net or cage
End caps: polypropylene
O rings: Silicone, EPDM, Buna, Viton
Dimensions (Nominal)
Length: 20”, 40”, 60”
Outer diameter: 6” (152mm)
Operating Parameters
Max. Temperature: Polypropylene 60℃
Glass fiber: 80℃
Max. Differential pressure: 50 psi (3.4 bar)
Recommended change out 35 psi (2.4 bar)
Ordering information
Code |
Media |
Core |
Length |
Micron |
Cage |
O-rings |
HFC |
P-PP F-Glass fiber |
P-PP N-coreless |
20-20” 40-40” 60-60”
|
1 5 10 20 50 75 100 |
N-pp net C-PP cage
|
S-Silicone B-Buna E-EPDM V-Viton |
