Specifications
Low pressure drop, long life serviceFull range of removal ratings
Graded pore density for high dirt holding capacity
Liquapure absolute rated filter cartridges, membrane filter cartridges, filtration products discriptions:
Full length filter cartridges designed with single piece outer cage which increased the intensity of filter cartridges; higher efficiency and consistent filtration of fluids in a wide range of critical applications.
Constructed of melt-blown filter media provides removal of particals from 0.1um to 50um. The high surface area ensures long service life and low initial pressure drops. All cartridges hardware components are high purity polypropylene materials for use in critical process application. Full length filter cartridges are available in a wide range configuration to fit most filter housings.
Liquapure absolute rated filter cartridges, membrane filter cartridges, filtration products typical applications:
- Pharmaceutics
- Food and beverage
- Oil industry
- Semiconductor
- Chemical industry
- Pre-filtration for RO system and UF system
- Paints and Coatings
- Cosmetics
- Photographic solutions
- Plating solutions
Liquapure absolute rated filter cartridges, membrane filter cartridges, filtration products features and specifications:
Features:
- Single-piece cage and core construction
- Excellent chemical compability. Suitable for filtering organic solvents, acid bases
- Pleated design increased filtration area and flow rate
- Low pressure drop, long life service
- Full range of removal ratings
- Graded pore density for high dirt holding capacity
- FDA compliance material
Specifications:
- Dimensions:
- Outer diameter: 2.6”(66mm), 2.7”(69mm)
- Length: 9.75”,10”,20”,30”,40”
Material of constructions:
- Filter media: PP
- Support/drainage:PP
- Cage/Core/End cap: PP
- Seal material: Silicone, EPDM, NBR,Viton, Teflon,E-FKM
Liquapure absolute rated filter cartridges, membrane filter cartridges, filtration products professional filters factory, we manufacture various kinds of cartridges:
Full length filter cartridges, filter cartridges, pleated filter cartridges,
absolute rated filter cartridges, membrane filter cartridges, filtration products
single filter cartridges, depth filter cartridges, high flow filter cartridges
water filtration, water filter cartridges, filter cartridges for filter housings
OEM is available, we can manufacture various kinds of cartridges according to your requirements
Liquapure absolute rated filter cartridges, membrane filter cartridges, filtration products
Ordering Guide
(Full length and single filter cartridges diameters)
Outer Diameter |
Removal Rating |
Length |
End Cap Type |
Seal Material |
|
66mm 69mm |
0.1um |
9.75” |
DOE |
Silicone |
0.22um |
10” |
215/flat |
EPDM |
|
0.45um |
20” |
222/flat/SS |
NBR |
|
1um |
30” |
222/fin/SS |
Viton |
|
3um |
40” |
222/flat |
Teflon |
|
5um |
|
222/fin |
E-FKM |
|
10um |
|
226/flat/SS |
|
|
20um |
|
226/fin/SS |
|
|
50um |
|
226/flat |
|
|
|
|
226/fin |
|
Welcome to contact with us Shanghai Liquapure Filtration Co.,ltd, professiona filter cartridges factory, welcome to visit our factory. we will service for you at any time and your satisfaction is our task.
