Copper Insulated Multi Core Cables1.type: Insulated
2.Application: Overhead Conductor
3.Material: Copper
Specifications
0.6/1 KV Three Core+One Reduced Core pvc Insulated Multi core Cable
ISO9001 CCC Certification
Copper Insulated Multi Core Cables
1.Products Application:
PVC insulated Power cables are fit for A.C rated voltages 600/1000V power transmission and distribution system
2.Products standards: BS 6346
3. Products characteristics:
--Long-term maximum working temperature of conductor should not be higher than 70°C, laying temperature should not be lower than 0 °C.
--Once short-circuit (the Max. duration 5s), the maximum conductor temperature does not be over 160 °C.
--Laying bending radius: Single-core and armored cables laying bending radius should not be less than 20 times of cable’s outer diameter value, however, multi-cores unarmored/armored cables laying bending radius should not be less than 15 times of cable’s outer diameter value.
