ZOOMLION QUY550H Crawler Crane (CE):
• Multiple safety protection of comprehensive video surveillance plus sound-light alarms;
• The swing mechanism is driven by an independently open hydraulic system.
• Independent hydraulic drive system and power-intensified hydraulic cooling system.
• Overall upgraded controllability, with the working speed, movement smoothness and micro-mobility perfectly integrated.
• The humanized intelligent design can fully meet the ergonomic demands.
• Mature and reliable supporting assembly configuration can achieve high cost performance.
Type |
Ser. No. |
Item |
Unit |
Value |
|---|---|---|---|---|
Boom section configuration |
1 |
Maximum lifting weight ×radius |
t×m |
55×3.7 |
2 |
Maximum lifting weight of fixed jib |
t |
5.5 |
|
3 |
Length of main boom |
m |
13~52 |
|
4 |
Length of fixed Jib |
m |
6~15 |
|
5 |
Longest main boom + fixed jib |
m |
43+15 |
|
6 |
Luffing angle |
° |
30~80 |
|
7 |
Fixed jib installation angle |
° |
10,30 |
|
Mechanism velocity |
8 |
Speed of rope on the drum of main winch |
m/min |
120/100 |
9 |
Speed of rope on the drum of auxiliary winch |
m/min |
120 |
|
10 |
Speed of rope on the drum of derricking winch |
m/min |
54 |
|
11 |
Swing speed |
rpm |
0~2.1 |
|
12 |
Travelling speed |
km/h |
0~1.6 |
|
|
13 |
Model |
/ |
WP6G190E26 |
Engine |
14 |
Type |
/ |
Inline 6-cylinder intercooled turbocharged diesel engine |
15 |
Rated power / speed |
kW/rpm |
140/1900 |
|
16 |
Maximum output torque / speed |
Nm/rpm |
830/1300 |
|
17 |
Displacement |
L |
6.23 |
|
18 |
Emission standard |
/ |
WP6G190E26 |
|
Others |
19 |
Gradeability |
% |
30 |
20 |
Pressure to the ground |
MPa |
0.069 |
|
21 |
Dead weight with basic boom attached |
t |
51 |
|
22 |
Total weight of complete configuration |
t |
57 |
|
23 |
Counterweight |
t |
17.5 |
|
24 |
Maximum transport weight of single part |
t |
32 |
|
25 |
Outline dimension length ×width ×height |
mm |
12800×4600(3300)×3120 |
|
26 |
Crawler gauge ×crawler length × crawler width |
mm |
2540×5000×760 |
|
3840×5000×760 |
