telescopic boom truck mounted crane XCMG QY25K-II truck mounted crane:
1. Main Technical Data Table in Travel configuration (Subject to improvement)
Category |
Item |
Unit |
Parameter |
|
Outline Dimensions |
Overall length |
mm |
12650 |
|
Overall width |
mm |
2500 |
||
Overall height |
mm |
3380 |
||
Wheel base |
mm |
4425+1350 |
||
Track |
mm |
2074/1834/1834 |
||
Weight |
Total vehicle mass in travel configuration |
kg |
29400 |
|
Axle load |
Front axle |
kg |
6200 |
|
Rear axle |
kg |
23200 |
||
Power |
Model |
|
SC8DK280Q3 |
|
Engine rated power |
kw/(r/min) |
206/2200 |
||
Engine rated torque |
N.m/(r/min) |
1112/1400 |
||
Travel Performance |
Max. travel speed |
km/h |
75 |
|
Min. turning diameter |
m |
21.5 |
||
Min. ground clearance |
mm |
275 |
||
Max. grade ability |
% |
30 |
||
Approach angle |
° |
16 |
||
Departure angle |
° |
13 |
||
Braking distance (at 30 km/h, full load ) |
m |
≤10 |
||
Oil consumption per 100km |
L |
≤37 |
||
Noise |
Exterior noise level during acceleration traveling |
dB (A) |
84 |
|
Noise level at seated position |
dB (A) |
90 |
||
2. Main Technical Data Table for Lifting Operation
Category |
Item |
Unit |
Parameter |
|||
|
Main Lifting Performance
|
Max. total rated lifting capacity |
t |
25 |
|||
Min. rated working radius |
m |
3 |
||||
Turning radius at turntable tail |
mm |
3065 |
||||
Max. load moment |
Base boom |
KN.m |
1010 |
|||
Fully-extended boom |
KN.m |
560 |
||||
Fully-extended boom + Jib |
KN.m |
376 |
||||
Outrigger span |
Longitudinal |
m |
5.14 |
|||
Lateral |
m |
6.0 |
||||
Hoist height |
Base boom |
m |
10.7 |
|||
Fully-extended boom |
m |
34.19 |
||||
Fully-extended boom + Jib |
m |
42.3 |
||||
Boom length |
Base boom |
m |
10.7 |
|||
Fully-extended boom |
m |
34.19 |
||||
Fully-extended boom + Jib |
m |
42.3 |
||||
Jib offset angle |
° |
0, 15, 30 |
||||
|
Working Speed Parameter |
Time for boom raising |
s |
75 |
|||
Time for boom lowering |
s |
45 |
||||
Time for boom extending fully |
s |
100 |
||||
Time for boom retracting fully |
s |
60 |
||||
Max. slewing speed |
r/min |
2.5 |
||||
Outrigger extending and retracting time |
Outrigger beam |
Extending Simultaneously |
s |
35 |
||
|
Retracting Simultaneously |
s |
30 |
||||
|
Outrigger jack |
Extending Simultaneously |
s |
40 |
|||
|
Retracting Simultaneously |
s |
35 |
||||
|
Hoisting speed (single line) |
Main winch |
Full load |
m/min |
85 |
||
No load |
m/min |
120 |
||||
Auxiliary winch |
Full load |
m/min |
85 |
|||
No load |
m/min |
120 |
||||
|
||||||
