Brand New ZOOMLION 30 Ton Hydraulic Truck Crane for Sale QY30V532

Name: Brand New ZOOMLION 30 Ton Hydraulic Truck Crane for Sale QY30V532
Brand: ZOOMLION
Availability: InStock

FOB Price

US$ 10 - 128,900 / Set

1 Set(Min. Order)

Port Shanghai qingdao tianjin
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	construction
Rated Loading Capacity	30ton	Rated Lifting Moment	1764kN.M
Max. Lifting Load	30 ton	Max. Lifting Height	51.6
Span	3000mm	Place of Origin	Henan, China
Brand Name	ZOOMLION	Model Number	QY30V532
Certification	3C,ISO	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Brand New ZOOMLION 30 ton hydraulic Truck Crane for Sale QY30V532 !!

• Weight optimized and distortion-resistant design of low-alloy and high-strength steel with U-type boom profile providing the max lifting height up to 48.5m.

• Optimized ergonomic design improves operation safety and work efficiency.
• Robust and powerful 3-axle special purpose chassis for truck crane, offering excellent road& off-road capabilities and driving reliability.

Item		Unit	Value	Remarks
Working performance	Max. rated lifting capacity	kg	30000
	Max. load moment of basic boom	kN.m	1132
	Max. load moment of main boom(fully extended)	kN.m	617.5
	Max. load moment of basic boom	m	11.1
	Max. lifting height of main boom	m	40.5	The parameters do not include deflection of main boom and jib
	Max. lifting height of jib	m	48.5
Working speeds	Max. hoist rope speed(Main winch)	m/min	120	At the 4th layer
	Max. hoist rope speed(Auxiliary winch)	m/min	100	At the 2nd layer
	Boom demrricking up time	s	40
	Boom demrricking up time	s	80
	Slewing speed	r/min	0 – 2.2
Driving parameters	Max. driving speed	km/h	78
	Max. gradeability	%	37
	Min turning diameter	m	≤22
	Min. ground clearance	mm	220
	Oil consumption per hundred kilometers	L	35
Mass	Deadweight in driving condition	kg	32000
	Complete vehicle kerb mass	kg	31870
	Front axle load	kg	7000
	Rear axle load	kg	25000
Dimensions	Overall dimensions(L×W×H)	mm	12900×2500×3465
	Longitudinal distance between outriggers	m	5.36
	Transversal distance between outriggers	m	Fully extended:6.10 m Intermediately extended:4.20 m
	Tail slewing radius	mm	3385
	Main boom length	m	10.6 - 40.0
	Boom angle	°	-2 - 80
	jib length	m	8.0
	Offset	°	0,30
