360 degree PIR sensor lamp holder ES-B03
- 10000 Piece / Pieces per Month
- NINGBO
- T/T L/C D/P D/A Credit Card
- IRR01001 irrigation set
- Tactical Grade Inertial Measurement Unit STIM300 IMU Factory Calibrated
- Low-power pressure switch BH-003025-003 Power plant procurement by Yoyik
- High-sensitive magnetic water level gauge UHZ-618C17 Chinese steam turbine by Yoyik
- Intelligent MONITOR JZ-MC-V for Bangladesh power system by Yoyik
- Wearable Motor management relay WDZ-5232 for Indonesia Thermal Power by Yoyik
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | ENERGYLUX | Model Number: | ES-B03 |
Usage: | Other, human motion detecting | Theory: | Hall Sensor | Output: | Switching Transducer |
Product Description
1.Detection Range: 360
2.Power Source: 110~240V/AC
3.Rated Load: <60W E27
4.Detection Distance: 6m
5.Time Delay: 10sec-5min
MODEL | DETECTION RANGE | DETECTION ANGLE | TIME SETTING | POWER SOURCE | POWER FREQUENCY | RATED LOAD | WORKING HUMIDITY | AMBIENT LIGHT |
ES-Z03 | 6m | 360° | 10sec-5min | 110V-130V/AC 220V-240V/AC | 50/60HZ | LED 5W MAX | <93%RH | 10LUX-2000LUX
|
WORK TEMPERATURE | INSTALLATION HEIGHT | NET WEIGHT FOR A CARTON (KG) | GROSS WEIGHT FOR A CARTON (KG) | QUANTITY PER CARTON | PACKING SIZE(cm) |
|
|
|
-10°C~+40°C | 1.5m-4m | 4.5 | 7.8 | 50 | 56.2*38.5*22 |
|
|
|
The product is a new saving-energy sensor, it adopts good sensitivity detector, integrated circuit. It gathers automatism, convenient safe, saving-energy and practical functions. It utilizes the infrared energy from human as control-signal source, it can start the load at once when one enters detection field. It can identify day and night automatically. It is easy to install and used widely.
INSTALLATION
- Fix the holder in the place where you will want to install according to right figure.
- After installation of the sensor, connect with lamp, then you could test it.
TEST
- After installation, Turned LUX knob clockwise to the maximum (SUN). Turned time knob anti-clockwise to the minimum(-).
- Turn on the power, the sensor will be electrify and warm-up, 30 sec later, the item will be entered into working estate. 5~10 seconds after the light goes out for the first time and then sensing, the load should be worked.
- Turns LUX knob anti-clockwise to the minimum. If it is tested under the circumstance below 3LUX, load should not work after induction load stop working; but if you cover the detection window with opaque objects (towel etc), the load works. Under the condition of no induction signals, the load should stop working within 5-15 sec.
E27 LAMP HOLDER 220V NINGBO
energy-saving switch(low consumption) wide used and very convenient
Model: | ES-B03 |
|
Power Source: | 110V-130V/AC 220-240V/AC | |
Power Frequency: | 50/60HZ | |
Detection Range: | 2-12M(adjustable) | |
Detection Angle: | 360° | |
HF System: | 5.8GHz CW radar, ISM band | |
Rated Load: | E27 60W Max | |
Time-Delay: | 10Sec±3Sec~2±30Sec(adjustable) | |
Ambient Light: | <3lux~2000lux(adjustable) | |
Working Humidity: | <93%RH | |
Installation Height: | 2m-3.8m |
PACKAGING DETIAL | one gift box for unit packing, 50 pieces in one master carton | By sea/air(avaible) |
N.W/G.W(KGS) | 5/6.7 | |
PACKING SIZE(CM) | 33*32*29 |
