ES-PL03 ,LED, Twilight Sensor Lamp

PIR ceiling lamp with 12 waits

SPECIFICATION:

Power Sourcing  220V/AC-240V/AC                              Detection Range: 360°

Power Frequency  50Hz                                                   Working Temperature -20~+40°C

Ambient Light 3-2000LUX (adjustable)                        Working Humidity  <93 RH

Time-Delay  10sec±3sec(min)                                      Installation Height  2.2m-4m

                      2min±30sec  (max)                                     Power Consumption 0.45W (work)

Rated Load  12 W(max)                                                                                         0.1W (static)

Detection Distance  max  6m (<24°C)                       Detection Motion Speed  0.6~1.5m/ s

FUNCTION

• It can identify day and nigh, and could choose the intensity of illumination what is in the working atmosphere by free. When turn the LUX knob to SUN symbol, it could be worked in any light, when turn to MOON symbol, it only could be worked in the night when the light is less than 3 LUX.
• Time Delay continues adding: after first inducting, when it receives the second induction signal again, the time delay will be re-clocking base on the first remainder time-delay (Set Time).
• Adjustable Time Delay: the length of time delay could be set according to the customers’ requirement, the minimum time of this item is 10sec ± 3sec, the maximum is 2 min ± 30sec.

TEST:

• Turn TIME knob anti-clockwise to the minimum; turn the LUX knob clockwise to the maximum (SUN), Switch on power, the controlled load should not work, needing to preheat within 5-30sec;
• Make it sense again 5-10sec later since the first is out, the load should work, the load should stop working within 5-15sec;
• Turn LUX knob to minimum anti-clockwise, if you test it when the ambient light is more than 3LUX, the induction load would not work after the load stops working; the load should work if you cover the detection window with opaque object (towel etc),it would be regular the load stops to work within 5-15sec under no induction signal condition
