2016 High Enquiry Automatic Brick Making Machine clay brick machine QT6-15
1. PLC (computer automatic control): Hundreds program and process are ready to install, suitable for complex dynamic environment, and easy to handle.
2. Multi-source vibration system: For ensure the accuracy, the vibration frequency is adjustable.
3. Automatic diagnosis system: Unique system, Real-time monitoring to find out the fault, achieved remote- control by using telephone line.
Main Technical Parameters
1, QT6-15 hydraulic block making machine main technical parameters
Parameter Name |
Parameter values |
|
The largest machine dimensions |
6600×1990×3000(L×W×H)(mm) |
|
Rated pressure of hydraulic system |
21Mpa |
|
Main vibration form |
All vibration molded desk |
|
Vibration frequency |
50~70Hz |
|
Vibration acceleration |
10-15g |
|
To adapt to the high brick |
50-200mm |
|
Pallet size |
Wooden |
830×660×(40±1)(mm) |
Iron |
830×660×(8-10±1)(mm) |
|
Bamboo |
830×660×(15-20)(mm) |
|
Molding cycle |
15-18 seconds 20-23 seconds to be added fabrics |
|
When production |
Standard block (240×115×53mm) |
57,600 Pieces/ 8 hours |
Feeder capacity |
Effective storage volume of 0.45m3 hopper |
|
|
Effective volume of 0.15m3 car charging |
|
Machine power |
36.8kw |
|
Machine weight |
12T |
|
