10t/h, 15t/h, 20t/h Mobile Asphalt Plant for Sale, Mobile Asphalt Mixing Plant for Sale

1

Productivity

  18-22t/h

2

Aggregate weighing accuracy:

  ±0.5%

3

Bitumen weighing accuracy:

 ±0.25%

4

Powder weighing accuracy:

  ±0.30%

5

Finished product temperature:

120-160( up to 180℃, adjustable)

6

Stability of hot material temperature

±5℃

7

Fuel consumption: based on the fuel calorific value=46055kj/kg, and under standard working condition

Aggregate moisture

≤3%, 5kg per ton hot mixed product.

Aggregate moisture

6kg per hot mixed product

Aggregate moisture

≤7%,6.5kg per hot mixed product

8

Screening efficiency

a)  ≥95%, (can satisfy the demands of various kinds of bituminous mixtures and eliminate large aggregates.)

9

Mixing cycle time

 140-180s, adjustable

10

Dust removing efficiency

 dust emission level≤100mg/Nm3

11

General power consumption

78.2Kw

12

Controlling mode

 full automatic operation, semi-automatic,manual operating for option

13

Hot material discharging height

 1590mm×3000mm(height×width)

14

Overall dimension

 L10.5m×W3m×H6m

Notes: Relating to Plant Capacity

1.The average moisture content is for surface moisture only.

2Ambient temperature taken as 15ºC.

3Material taken as 1600kg per cu.m.

4Capacities include filler and bitumen.

5Aggregate feed to plant is in correct proportion required for mix specifications.

6Powder density 1120kg per cu.m.

7Aggregate is non-porous and not excessively flaky.

8Altitude 150m above sea level.
