JBZ-A12 Best-selling Korea Paper Cup Machine

JBZ-A12 Best-selling Korea Paper Cup Machine thumbnail-1
JBZ-A12 Best-selling Korea Paper Cup Machine photo-1
US$ 8,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Product Type:
Paper Cup Machine
Processing Type:
Paper Folding Machine
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Wenzhou Qichen Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Type Paper Cup Machine
Processing Type Paper Folding Machine
Place of Origin Zhejiang, China
Brand Name QC
Model Number ZBJ-A16
Certification CE
Weight 1500KG

Specifications

1:Long life of the machine.
2:Automatic working machine.
3:Available for 12oz ~ 16oz paper cup.

ZBJ-A16 Automatic Ultrasonic Fully Paper Cup Machine which is good for making 12oz ~ 16oz paper cup. Products of all parts of detailed introduction is as follows :





1 ) normal type an incline horse.



2 ) Arm-and-hand systems which use arm to pick the cup drop in to plastic hole. It makes the drop cup 99.9999.



3) Some bearing import from out of china.



4) Contractor:Zhengtai brand (The biggest electric parts supplier in china)



5)Inside of the machine , using big size of chains



6) Machine body material is SS









Technical Specification:

Model

ZBJ-A16 AUTOMATIC Ultrasonic Paper Cup Machine

Paper Cup Size

12oz~16oz (mold exchangeable)350ml~ 450ml

Raw Material

One-side or two side PE (polyethylene) film coated / laminated pape

Suitable paper weight

140-350gsm

Rated Productivity

40-50 pcs/ minute

Power Source

220V/380V 50Hz or other required

Total Power

4.8KW

Total Weight

1500KG

Package Size

(L x W x H)

3000 x1350 x1950mm

Working Air Source

0.4Mpa, Air Out-put:0.6 m3/minute

Making Double PE coated paper cups, need to buy an air compressor



Compare Bevel type with normal type

Normal type: 9 oz / 210ml

JBZ-A12 best-selling korea paper cup machineJBZ-A12 best-selling korea paper cup machineJBZ-A12 best-selling korea paper cup machine

Description: (one-side PE paper 200gsm, price USD 1000 per ton for example)

A. 845.2mm x 669.51mm sheet paper, can make 24 pieces 9oz cup-fan-body ;

B. One cup-sheet-body need paper weight : 200 x 0.8452 x 0.66951 / 24 == 4.715g

C. One ton 200 gsm paper can make : 1000 000 / 4.715g = 212 089pieces cups;

D. One 9oz cup cost : 1000USD / 212 000 == 0.00471 USD



Bevel type:

  JBZ-A12 best-selling korea paper cup machineJBZ-A12 best-selling korea paper cup machineJBZ-A12 best-selling korea paper cup machine

Description: (one-side PE paper 200gsm, price USD 1000 per ton for example)

A.  659.3mm x 785.66mm sheet paper, can make 24 pieces 9oz cup-fan-body ;

B.  One cup-sheet-body need paper weight : 200 x 0.6593 x 0.78566 / 24 == 4.3165g

C.  One ton 200 gsm paper can make : 1000 000 / 4.3165g = 231 669 pieces cups;

D.  One 9oz cup cost : 1000USD / 231 500 == 0.00431 USD

From above information: bevel type is more save paper 10% than normal  type



<Each set machine goes together with a set of free molding and a set of free accessories.>
