Product Description
Paper Box Machine
Paper Box Machine : Paper Box Machineadopt HMI and PLCcontroller, imported electronnics, feeding unit controlled by separately motor and inverter, railway running, keep the machine performance atable ,easy control and easy operate.
Paper Box Machine : an idea equipment of making 4 conner or 6 conner box (box with cover and fold),Carton box ,cardboard carton I.E. Which the box widely uesd for snacks, cake, muffin, ect food package.
1.Size of 6 folds box and folding box:
| Item/Model | 780Type | 980 Type | 1050 Type | 1450 Type | |
| A | MAX | 650 | 800 | 900 | 1200 |
| MIN | 300 | 300 | 400 | 400 | |
| B | MAX | 500 | 600 | 600 | 700 |
| MIN | 150 | 200 | 200 | 300 | |
| C | MAX | 100 | 100 | 100 | 100 |
| MIN | 25 | 25 | 25 | 25 | |
2. Size of 4 corners box and folding box
| Item/Model | 780Type | 980 Type | 1050 Type | 1450 Type | |
| A | MAX | 650 | 800 | 900 | 1200 |
| MIN | 150 | 180 | 200 | 250 | |
| B | MAX | 500 | 600 | 600 | 700 |
| MIN | 120 | 150 | 200 | 200 | |
| C | MAX | 100 | 100 | 100 | 100 |
| MIN | 25 | 25 | 25 | 25 | |
3.Size of bottom-locked carton and folding carton
| Item/Model | 780Type | 980 Type | 1050 Type | 1450 Type | |
| A | MAX | 750 | 950 | 1020 | 1420 |
| MIN | 180 | 200 | 250 | 250 | |
| B | MAX | 500 | 600 | 700 | 800 |
| MIN | 80 | 100 | 120 | 120 | |
| H | MAX | 100 | 100 | 100 | 100 |
| MIN | 25 | 30 | 30 | 30 | |
4.Carton type and size:
| Item/Model | 780Type | 980 Type | 1050 Type | 1450 Type | |
| A | MAX | 750 | 950 | 1020 | 1420 |
| MIN | 120 | 200 | 250 | 250 | |
| B | MAX | 800 | 900 | 1000 | 1200 |
| MIN | 60 | 60 | 80 | 100 | |
Paper Box Machine
1.Feeding section
a. Paper Box Machine : auto feed correctly and continuously, internal of feeding is adjusted by continuously variable speeder;
b. Paper Box Machine: independent high-speed feeding bell can be easily adjusted;
c. Paper Box Machine: independent vibrating motor can improve feeding greatly;
d. Paper Box Machine: feeding blade and baffle on the left and right can be adjusted upper and down to shorten adjusting and carton changing time.
2.Folding
a. Paper Box Machine: long-distant folding ensure the first line 180°, the third 135° to easily open the cartons fully filled;
b. Paper Box Machine: all parts can be easily replaced, which is convenient to install other components for other kinds of cartons.
3.Bottom folding
a. Paper Box Machine: The entire bottom-lock part is installed in a reversible bracket, substantially reduce the swap adjustment time of bottom-fold box and the other types of box.
b. Paper Box Machine: Bottom-folding speed is 50-400 pcs per min, stable and reliable
4.Folding
a. Paper Box Machine: Lengthened folding to avoid the unevenness while the rapid forming of cartons and make it come to perfection.
5.Full pressing
a.Paper Box Machine: Pressure can be adjusted conveniently, reliable, ensure good quality of gluing
b. Paper Box Machine: Automatic Pre-Folding and Bottom Lock Folder Gluer Machine(QH-SLJ)es to match with boxes regulating, easy to count and pack
6.Transmission
Paper Box Machine: Structure is specially designed, pressure adjustment is easy and reliable to ensure the quality of gluing;
7.Collecting
Paper Box Machine: Press is equipped with independent speeding device, the operator can set the paper collecting speed according to the packing speed.
8.Spraying System
Paper Box Machine: Equipped with three guns, convenient in the production of 4/6 corner box and various special-shaped box, gluing quickly and accurately sizing.
9.Servo motor
Paper Box Machine: Corrugated Paper Box Die Cut Machine Reliable (QH-SLJ): The servo control system, assistant with PLC and signal collection operation system, to fold each product (4, 6 corners box) correctly, ensure perfect quality.
We provide not only the equipment but also the solve ways.
