Prefab house (ZA) type is a flexible product. When delivery, it is knock-down to save the space. When erection, it could be installed by common worker with electric tools according to instruction and CD. Four persons can finish 40m2 in 8 hours. The structure is connected by bolt and the wall is fixed by rivet. Light material without overload, easy to pack and transport.
The detailed information as follow:
No. | Sort | Name | Specification |
1 | Specification | length | No limited |
2 | Width | No more than 12m | |
3 | Wall height | 3200mm | |
4 | Clear height | 2800mm | |
5 | Roof slope | 1:5 | |
6 | Standard accessory | Wall board | 75mm thickness sandwich panel, 0.35mm steel sheet, 13kg/m3 polystyrene density. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/m²..k. |
7 | Roof board | 75mm thickness sandwich panel, 0.35mm steel sheet, 13kg/m3 polystyrene density. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/m².k. | |
8 | Outside door | Security door, single door with dimensions of 900*2100mm, furnished with a handle lock with 3keys. Doorframe is made of 1.2mm steel, and door is made of 0.7 mm steel, 90mm thick rock wool insulation foam. | |
| Inside door | SIP, single door with dimensions of 750*2000mm, furnished with a cylinder lock with 3keys. Doorframe is made of aluminum, 50mm thick EPS insulation foam. | |
9 | Window(W-1) | PVC, white color, with dimensions of 1200*1200mm, glazed with glass in a thickness of 5mm, two bay fixed, and two bay sliding, supplied with fly screen. | |
| Window(W-2) | PVC, white color, with dimensions 500*500mm, glazed with glass in a thickness of 5mm, casement opening, supplied with fly screen. | |
10 | Channel | Galvanized Steel Plain Sheet press moulding Material: Q235. Painted | |
11 | Post | Square steel tube, Material: Painted steel | |
12 | Purline | C style steel Material: Painted steel | |
13 | Roof truss | Gabled truss, Material: Painted steel | |
| Decoration and connection | Color steel sheet, 0.35mm thick | |
| Elevated ceiling | Ceiling of mineral wool acoustic panel in room and aluminium panel in bathroom and kitchen | |
20 | Option | Decorative floor | PVC, laminated or ceramic tile |
21 | Drainage system | Provided plan, design and construction | |
22 | Electric system | Provided plan, design and construction | |
25 | Technical parameter | Bearing load | 50kg/m2, can be adjusted according to climate |
27 | Wind pressure: | 0.5KN/M2, can be adjusted according to climate | |
28 | Fire proof | B2 grade | |
29 | Resistant temperature | -25ºC to 50ºC | |
30 | The resistant earthquake grade | 7 fission activate. |
