Module House, Modublar House for Construction Site Office With Electricity

No.

classification

Name

Specification & Parameter

1

Size

Length:

(n-2)*1224+2*1100mm (N stands for number of groups in length,n=4,5,6…),can be extended freely

2

Width:

5060mm which is fixed dimension

3

Wall height

2700mm/3750mm

4

Indoor Net height

2450mm(Lowest place)

5

Standard layout

Ground Channel

Z50*60*30mm profiled bar

6

Column

H-shape steel pillar

7

Roof girder

Upper chord is T shape section, a tension rod in the
bottom

8

Roof board pressure channel

C type steel,

9

Wall board

50mm thick double sides color steel sheet with EPS sandwich panel (white in both sides),heat conduction coefficient≤0.041w/(m·k)

10

Roof board

60mm thick double sides color steel sheet with polystyrene insulation sandwich panel, upper face color is blue or red, under surface is white,heat conduction coefficient≤0.041w/(m·k)

11

Door

SIP door,800mm*2000mm

12

Windows

Color steel windows,1200mm*1000mm,blue,red or white

13

Optional

Ceiling

Mineral wool acoustic board ceiling,PVC ceiling,aluminous gusset ceiling or calcium silicate board

14

Elevation Floor

Adjustable height

15

Eaves

Composed of steel frame and color steel corrugated sheet.

16

Door

Color steel door or security door

17

Water plumbing

Supply planning, designing and technical service

18

Electric

Supply planning, designing and technical service

19

Technical data

Roofing live load

0.5KN/sqm

20

Wind resistance

1 0 grade(or wind load 0.5KN/sqm)

21

Earthquake resistance

7 degree seismic intensity
