MINI EXLAS LASER CUTTER6040

Name: MINI EXLAS LASER CUTTER6040
Brand: EXLAS
SKU: 123099211
Availability: InStock

US$ 3,000 - 6,000 MOQ: 1 Set

Key Specifications

Laser Type:

CO2

Place of Origin:

Shandong, China

Brand Name:

EXLAS

Jinan XYZ Machinery LLC

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Laser Type CO2

Place of Origin Shandong, China

Brand Name EXLAS

Model Number 6040

Specifications

Advertising industry
Packing and printing
Leather engraving
Carved gifts and crafts
Architectural model making

Machine Description	EXLAS6040 Laser Engraving and Cutting Machine
Machine Performance:
Laser-type	Hermetic and detached CO2 laser tube
Laser-power	60W
Cooling Mode	Circulating-water-cooling
Power Adjustment	0-100% controlling, no segment and adjusting by software
Machine Control and Drive	Speedy DSP controlling, stepper motor
Max Engraving Speed	60000mm/min
Max Cutting Speed	500mm/min(when cutting 10mm thick of acrylic)
Repeating Location	0.01mm
Minimum Character	Chinese character 1.5mm, crisscross-row 1mm
Max Power	750W
Adjustable Up-down Distance of Laser Head	30mm
Working Travel Area	600x400mm, 600mm width with infinity material-feeding
Table Area	650x950mm
Up-down Range of Working Table	Mechanical 280mm
Working Voltage	AC220V 50Hz
Working Environment	Temperature: 0-45¡æ, Humidity: 5%-95%, and congeal-water removed
Controlling Software Language	English, Simplified Chinese, Traditional Chinese and procuring of multi-languages
Dictate Format	.plt,.dst,.dxf,.bmp,.dwg,.ai,*las, Support AutoCAD,CoreDraw direct outputting

Body Dimension (LxWxH)	1480x880x900mm
Packaging Dimension (LxWxH)	1640x1020x1060mm
Packaging	Plywood Case
Gross Weight	140kg
Machine Color	Customizable
Delivery Time	15 days
Payment	T/T

Optional Equipment	Rotary attachment
	Motorized up-down table
	Water-cooling unit
	Red-light position
	Vacuum table
	DSP Off-line operation with usb flash
