Specifications
1.linear square rails2.welded steel structurer
3.large power spindle
4 T slot(vacuum )table
5 1 year warranty
XYZ-1325 CNC Router:
The working area of 1300x2500mm can meet the demands of engraving and cutting on big size matrials such as arylic, cloth, leather, wood, plastic and paper industry.and big power laser tube(80W,100W,150W,180W) adopted can ensure big thickness material being cutted through with very good performance.
Supply with CE certificate, FDA
Specification:
1) Engraving area: 1300 x2500mm (we can also customize you bigger size like 1500x3000mm)
2) Whole machine size: 3200 x 1900x 1380mm
3) Laser power: 80W(optional 100W,150W,180W)
4) cutting speed: 0 - 12000mm/min
5) Resetting positioning accuracy: ¡À0.1mm
6) Power supply: AC 110 - 220V ¡À10%, 50 - 60Hz
7) Gross power: <1,000W
8) Operating temperature:0-45¡ãC
9) Operating humidity: 8 - 95%
10) Minimum shaping character: English 1 x 1mm
11) Graphic format supported: BMP, HPGL, PLT, DST, DXP, and AI
12) Driving system: stepper
13) Cooling mode: water-cooling and protection system (water flow and temperature safty alarm system included)
14)Auxiliary equipments :Exhaust-fans, air-exhaust pipe
15)Controlling software : DSP control system.
16)Compatible software: CorelDraw AutoCAD
17)Laser- type: Sealed CO2 laser tube
18)Net Weight:570KG
Applicable materials: wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
Applicable industries: advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry
